Zyxel LTE-A Id Router/IAD, Home WiFi Router, LTE5366
Description
Zyxel LTE-A Id Router/IAD, Home WiFi Router, AC2050 MU-MIMO dual-band wireless LAN, Non-stop connectivity with LTE 2nd WAN for fail-over, LTE5366
The Zyxel LTE5366-M608 4G LTE-A Indoor IAD provides users with mobile broadband connectivity to take advantage of the latest carrier aggregation technology compatible with LTE, DC-HSPA+/HSPA/UMTS and EDGE/GPRS/GSM that allows users to connect with a variety of mobile broadband services all over the world. You can enjoy Triple-Play services, watch IPTV and listen to high-fidelity music and easily surf the Internet at home, in the office or anywhere within LTE/3G coverage without wire limitation.
Lightning-fast Internet connectivity
The Zyxel LTE5366-M608 is a pioneering portable router with LTE category 6 compliance. The carrier aggregation technology delivers downlink data rates of up to 300 Mbps — twice which of the category 4 and is better than the fixed-line Ethernet — thanks to the modern technology, you can enjoy lightning-fast Internet now.
AC2050 MU-MIMO dual-band wireless LAN
The Zyxel LTE5366-M608’s latest MU-MIMO 802.11ac technology is perfect for busy environments: it doubles WiFi performance of Single User MIMO (SU-MIMO) in venues where concurrent wireless access activities are intensive.
Non-stop connectivity with LTE 2nd WAN for fail-over
Multi-WAN fail-over relieves the risk of network outage caused by dependence on single-WAN technology. Even better, LTE is wireless so you can get the second WAN without an additional cabling plan. As long as the gateway supports “multi-WAN fail-over”, you can just connect the Zyxel LTE5366 to the existing gateway and set LTE as the fail-over WAN.
Features
Ports & interfaces | |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 4 |
DC-in jack |
Yes
|
USB port | Yes |
Weight & dimensions | |
Height | 30 mm |
Width | 230 mm |
Depth | 160 mm |
Energy management | |
Power consumption (typical) | 20 W |
Power source type | AC |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -30 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 0 - 95% |
Protocols | |
DHCP client | Yes |
DHCP server | Yes |
Networking | |
Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Dynamic DNS (DDNS) | Yes |
VPN Passthrough | Yes |
Security | |
Security algorithms | WEP,WPA,WPA2 |
IP address filtering | Yes |
Firewall | Yes |
Filtering | Yes |
Wireless LAN features | |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) | 1733 Mbit/s |
WLAN data transfer rate (first band) | 300 Mbit/s |
WLAN data transfer rate (second band) | 1733 Mbit/s |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Management features | |
Reset button | Yes |
WPS push button | Yes |
Ethernet LAN features | |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN interface type | Gigabit Ethernet |
Antenna | |
Antenna type | Internal |
Design | |
LED indicators | Power,USB,WAN,WLAN |
Wall mountable | Yes |
Product colour | White |
On/off switch | Yes |
Product type | Tabletop router |
Mobile networking | |
3G | Yes |
GSM bands supported | 850,900,1800,2100 MHz |
UMTS bands supported | 900,2100 MHz |
4G bands supported | 800,850,900,1800,2100,2300,2600 MHz |
4G | Yes |
4G standard | LTE |
3G standards | HSPA+,UMTS |
2G standards | EDGE,GPRS,GSM |
WAN connection | |
WAN connection type | RJ-45 |
Ethernet WAN | Yes |
SIM card slot | Yes |
3G/4G USB modem compatibility | Yes |
EAN | 4718937597062 |
Warranty | 2 years |
