Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE) Wireless Access Point
|14:771#with power|14:193#without power|3256805471676078-with power|3256805471676078-without power
  • Load image into Gallery viewer, Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE) Wireless Access Point
  • Load image into Gallery viewer, |14:771#with power|14:193#without power|3256805471676078-with power|3256805471676078-without power

Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE) Wireless Access Point

Regular price
R 7,373.95
Sale price
R 7,373.95
Regular price
R 7,456.95
Sold out
Unit price
per
Shipping calculated at checkout.

Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE)

Description

airMAX NanoStation 5AC Loco

Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE) Wireless Access Point

Loco5AC

Compact, UISP-ready WiFi radio sporting a classic NanoStation design and an updated airMAX AC chipset.

5 GHz, 10+ km link range

450+ Mbps throughput

Dedicated spectral analysis radio

SPECIFICATIONS

Size: 179*77.5*59.1

Model Number: Loco5AC

Item Type: Video Converter

Certification: FCC

Certification: CE

Technical Specifications

Mechanical
Dimensions 179 x 77.5 x 59.1 mm (7.1 x 3.1 x 2.3")
Weight 180 g (6.4 oz)
Enclosure material UV-stabilized plastic
Mounting Pole mounting kit (Included)
Hardware
Networking interface (1) GbE RJ45 port
Power method Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply 24V, 0.3A gigabit PoE supply (Not included)
Supported voltage range 22–27V DC
Max. power consumption 7W
LEDs Power, Ethernet, (4) signal strength
Ambient operating temperature -40 to 70° C (-40 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
System
Gain 13 dBi
Channel bandwidths 10/20/30/40/50/60/80 MHz
Cross-pol isolation 20 dB min.
Max. VSWR 1.8:1
Beamwidth 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
Polarization Dual linear
Operating Frequency (MHz)
Worldwide 5150-5875 MHz
USA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3

5150-5250 MHz
5250-5350 MHz
5240-5725 MHz
5725-5850 MHz
Management Radio (MHz)
Worldwide 2412 - 2472 MHz
US/CA 2412 - 2462 MHz


Product Details

The Ubiquiti NanoStation Loco5AC NS-5ACL UISP airMAX NanoStation 5AC Loco WiFi Bridge PtMP station (CPE) Wireless Access Point was built with people like you in mind. Something to keep you happy. Every. Single. Day.

Inventory Last Updated: Jan 13, 2025
