TP-Link TL-CPE500G outdoor built-in 13dBi antenna 5G CPE/AP Gigabit RJ45 Wireless Bridge 867M 5Km 1pc/2pcs/3pcs/4pcs

TP-Link TL-CPE500G outdoor built-in 13dBi antenna 5G CPE router full Gigabit RJ45 port Wireless bridge Access Point TL-CPE500G 867M 5km 1pcs/2pcs/3pcs/4pcs

SPECIFICATIONS

2.4G Wi-Fi Transmission Rate: None

5G Wi-Fi Transmission Rate: 867Mbps

5G Wi-Fi Transmission Rate: 867Mpbs

Application: Outdoor,Outdoor

Brand Name: TP-LINK

Certification: None

Function: QoS

LAN Ports: 1,1

Language: Chinese with English User Manual

Max. LAN Data Rate: 867Mbps

Number of USB Interfaces: None,None

Package: Yes

Standards And Protocols: Wi-Fi 802.11ac,11AC

Supports WDS: Yes,Yes

Supports WPS: Yes

Type: WireLess,Wireless

WAN Ports: 1 x10/100Mbps,1 x10/100Mbps

Wi-Fi Supported Frequency: 5G,5G

Wi-Fi Transmission Standard: 802.11ac

Wired Transfer Rate: 10/100Mbps,10/100Mbps

With Modem Function: No,NO

Note: The product is packaged in single piece, the product setting language is Chinese, and we provide English user manual. Two Piece (2pcs) are needed for the best effect.

Description

5GHz AC867 outdoor wireless CPE TL-CPE500/TL-S5-5KM

>Professional outdoor housing design, adapt to various harsh environments

>867M wireless, built-in high gain 13dBi dual-polarized antenna, provide high performance wireless

>Pure 5GHz frequency band, less interference, wireless transmission distance 5 kilometers

Hardware specifications

>Installation method: Pole-mounted installation

>Wireless standard IEEE 802.11a/n/ac

>Wireless rate 867Mbps

>Wireless operating frequency band: 5.15~5.25GHz, 5.735~5.835GHz

>Maximum transmit power 20dBm

>Antenna built-in 13dBi dual-polarized antenna

> Maximum wireless transmission distance (under non-interference environment) 5 KM

>Interface 1 10/100Mbps RJ45 port (LAN0/POE) 1 10/100Mbps RJ45 port (LAN1)

>Power supply mode 24V/0.25A Passive PoE power supply, power supply distance is up to 55M

>Indicators PWR, LAN0, LAN1, 4 signal strength indicators

> Antenna coverage angle Horizontal direction: 45° Vertical direction: 30°

> Product size 224x79x60(mm)

> Use environment working temperature: -30°C~70° C Storage temperature: -40℃～70℃ Working humidity: 10%～90%RH non-condensing Storage humidity: 5%～90%RH non-condensing

> Dustproof and waterproof grade ASA engineering plastic shell, IP55 grade dustproof and waterproof

>Whether to support wide-voltage power supply network bridge Support wide-voltage power supply: 9V-25V

>Power adapter 24V/0.25A

>The maximum power of the whole machine is 4.654W (without power adapter) 5.61W (with power adapter)

Software specifications

>Wireless working mode AP, Client

>Network setting LAN port connection: static IP, dynamic IP

>Wireless setting 802.11a/n/ac mode automatic channel selection Transmit power adjustment WDS wireless security: WPA/WPA2, WPA-PSK/WPA2 -PSK (AES/TKIP) encrypted SSID broadcast/hidden distance setting channel bandwidth selection advanced settings: Beacon time slot, RTS threshold, fragmentation threshold, DTIM interval, AP isolation, Short GI, WMM

> Manage and maintain HTTP/HTTPS WEB management system Log time and NTP settings Ping watchdog

> System tools System status: signal strength, noise strength, transmission CCQ, CPU occupancy, memory occupancy Status monitoring: throughput/wireless client/interface/ARP spectrum analysis rate test Ping Traceroute

>System optimization IGMP Snooping optimization hardware watchdog
