Scodeno Industrial Etherent Switch Unmanaged IP40 DIN-Rail DC12~58V input Voltage, 1G switching, Fanless, XPTN-9000-45-5TXm

SPECIFICATIONS

Brand Name: Scodeno

Buffer: 768K

Bus topology: Support

Certification: CE,FCC,RoHS

Communication Mode: Full-Duplex & Half-Duplex

Dual Power Supply: YES

ESD: 8K/15K

Flow control: Support

Forwarding delay: <5us

Hign-concerned Chemical: None

IP Level: IP40

Input voltage: DC12~58V

Installation Method: DIN-rail

Jumbo frame: 2K bytes

LED Indicators: P1/P2, OPT

MAC address table: 2K

MDX/MIDX: Support

MTBF: 100,000 hours

Model Number: XPTN-9000-45-5TXm

Number of Interfaces: 7

Operating temperature: -30℃~+75℃

Package: Yes

Packet forwarding rate: 0.744Mpps

Port-Isolation: Support

Power Interface: Phoenix terminal

Product size: 91*118*31mm

Relative humidity: 10%~90%

Remote PD Reset: Support

Ring Topology: Unsupported

Star topology: Support

Storage temperature: -30℃~+75℃

Storm Control: Support

Surge protection of Ethernet port: 4KV/2KV

Surge protection of Power: 4KV/2KV

Switch Capacity: 1G

Switch Type: Fast Switch

Thermal methods: Fanless, natural cooling

Total Power consumption: <5W

Transmission Rate: 10/100Mbps

Tree Topology: Support

VLAN: yes

Estimated Weight: 0.36KG

Description

Scodeno Industrial Etherent Switch Unmanaged IP40 DIN-Rail DC12~58V input Voltage, 1G switching, Fanless, XPTN-9000-45-5TXm

The unmanaged switches from Scodeno are a cost-effective way of entering the world of Industrial Ethernet technology without compromising on quality and reliability. All switches have been specially designed for use in harsh environments and come with all the necessary certifications. They are suitable for all applications in which switch management is unnecessary: at field level in industrial networks, for example, or in smaller infrastructures.

With its extremely wide range of industry-grade unmanaged switches, Scodeno is able to provide the ideal solution for every customer and every area of application. As well as switches with a redundant power supply and signal contact, the portfolio also features devices with a robust IP40 housing for use in the most demanding environments. Our portfolio is rounded off by certifications for a wealth of application areas, including those for vehicles, potentially explosive environments and transformer substations.
Whether you need a cost-effective, entry-level switch - or something more robust, with many customizable features - the Scodneo will meet your network's unique needs.

The Scodeno Industrial Etherent Switch Unmanaged IP40 DIN-Rail DC12~58V input Voltage, 1G switching, Fanless, XPTN-9000-45-5TXm is a sensational customer favorite, and we hope you like it just as much.
