MikroTik hEX PoE 5-Port Gigabit 1SFP Desktop Router - with 128MB RAM - 1 Core 800MHz QCA9557 CPU - Passive PoE - RouterOS L4 - 1.25Gbps SFP | RB960PGS

MikroTik hEX PoE 5 Port Gigabit 1SFP PoE Out Desktop Router | RB960PGS

Description

MikroTik's RB-HEXPOE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and an SFP port for adding optical fibre connectivity. Ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. This powerful 800MHz CPU is a cost-effective, small, easy to use and capable of all the advanced configurations supported by RouterOS. The maximum current is 1A per port and the Ethernet ports are shielded.

hEX PoE

5x Gigabit Ethernet with PoE output for four ports, SFP, USB, 800MHz CPU, 128MB RAM, RouterOS L4

hEX PoE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit.

It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded.

It also supports passive PoE input and passive or 802.3af/at PoE output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power at/af mode B (4,5+)(7,8-) compatible devices, if 48-57 input voltage is used.

Features

Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 12V-57V (Passive PoE, 802.3af/at)
PoE Output: 12V-57V Passive PoE, 802.3af/at on Ports 2 to 5
Power Input: 24V 2.5A Power Supply (Included)
Processor: 1 Core 800MHz, QCA9557
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 12V-57V
System Memory: 128 MB
USB Ports: 1x USB 2.0
Other: None

Dimensions: 114 x 137 x 29mm

Specifications

Powering

PoE-out

Ethernet

Fiber

Peripherals

Other

Certification & Approvals

Included parts

•
  24V 2.5A power adapter
•
  IEC cord
