Mikrotik hap ax2 C52iG-5HaxD2HaxD-TC 2.4 GHz/5 GHz 600Mbps/1300Mbps hAP 4.5dBi US hAP Wireless Router Wi-Fi Access Point
SPECIFICATIONS
Brand Name: MikroTik
Hign-concerned Chemical: None
Compatible Audio & Video Equipment Style: Earphones & Headphones
Compatible Audio & Video Equipment Style: Speakers
Compatible Audio & Video Equipment Style: Amplifier
Compatible Audio & Video Equipment Style: player
Compatible Audio & Video Equipment Style: Digital-to-Analog Converter (DAC)
Compatible Audio & Video Equipment Style: Professional Audio Equipment
Compatible Audio & Video Equipment Style: Stage Equipment
Compatible Audio & Video Equipment Style: Recording Equipment
With Modem Function: NO
Standards And Protocols: Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n, Wi-Fi 802.11ac, Wi-Fi 802
Wi-Fi Supported Frequency: 2.4G & 5G
Supports WDS: Yes
Supports WPS: No
2.4G Wi-Fi Transmission Rate: 600Mbps
Encryption Type: WPA2-PSK, WPA2, WPA3, WPA-PSK, WPA, WEP, WPA3-PSK
Private Mold: NO
Products Status: New
Type: Wireless
Application: Multi-service
Function: QoS
LAN Ports: 4
WAN Ports: 1
Brand Name: MikroTik
5G Wi-Fi Transmission Rate: 1300Mbps
Product name: MIKROTIK WiFi 6 Dual Band Dual Chain Router hAP ax²
Model Number: C52iG-5HaxD2HaxD-TC
MOQ: 1 PC
Condition: 100% Original Brand
Product Status: Stock
Warranty: 1 year warranty+life service
Product Description
MIKROTIK WiFi 6 802.11AX Wave 2 PoE in/out Dual Band Dual Chain Router hAP ax² (C52iG-5HaxD2HaxD-TC)
A Generation 6 version of the legendary hAP ac². With PoE-in and PoE-out, much faster wireless, more RAM, and a modern CPU. The smallest fully-fledged AX router on the market!
It’s time to supercharge your home network with the Generation 6 wireless network and our latest addition to the beloved hAP series. hAP ax² has everything you might need in a primary home access point – and more! Forget endless reviews and comparisons – this is the perfect device for 99% of homes.
Wireless signal is now stronger than ever. Here are the two main ingredients of hAP ax’s success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let’s compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
Some might ask – why do we even need higher wireless speeds? Well, countless use cases have been previously impossible or difficult to pull off. For example, working with large media files over the wireless network – without the need to download and upload everything. Do you really have the time to wait? Grab a hAP ax² and save more time for the essential things in life!
The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.
Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall – without sacrificing the strong signal.
With so many products and features on the market, even an experienced user can become confused. So it’s time for a simple truth for a simple choice: you can’t go wrong with a hAP ax² in most homes.
C52iG-5HaxD2HaxD-TC Specification |
||
Product code |
C52iG-5HaxD2HaxD-TC |
|
Architecture |
ARM 64bit |
|
CPU |
IPQ-6010 |
|
CPU core count |
4 |
|
CPU nominal frequency |
864 MHz |
|
RouterOS license |
4 |
|
Operating System |
RouterOS (v7 only) |
|
Size of RAM |
1 GB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
MTBF |
Approximately 100'000 hours at 25C |
|
Tested ambient temperature |
-40掳C to 50掳C |
|
Wireless capabilities |
||
Details |
||
Wireless 2.4 GHz Max data rate |
574 Mbit/s |
|
Wireless 2.4 GHz number of chains |
2 |
|
Wireless 2.4 GHz standards |
802.11b/g/n/ax |
|
Antenna gain dBi for 2.4 GHz |
4.5 |
|
Wireless 2.4 GHz chip model |
QCN-5022 |
|
Wireless 2.4 GHz generation |
Wi-Fi 6 |
|
Wireless 5 GHz Max data rate |
1200 Mbit/s |
|
Wireless 5 GHz number of chains |
2 |
|
Wireless 5 GHz standards |
802.11a/n/ac/ax |
|
Antenna gain dBi for 5 GHz |
4 |
|
Wireless 5 GHz chip model |
QCN-5052 |
|
Wireless 5 GHz generation |
Wi-Fi 6 |
|
WiFi speed |
AX1800 |
|
Ethernet |
||
Details |
||
10/100/1000 Ethernet ports |
5 |
|
Number of 1G Ethernet ports with PoE-out |
1 |
|
Powering |
||
Details |
||
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
12-28 V |
|
Max power consumption |
27 W |
|
Max power consumption without attachments |
12 W |
|
Cooling type |
Passive |
|
PoE in |
Passive PoE |
|
PoE in input Voltage |
18-28 V |
|
PoE-out |
||
Details |
||
PoE-out ports |
Ether 1 |
|
PoE out |
Passive PoE |
|
Max out per port output (input 18-30 V) |
600 mA |
|
Max total out (A) |
0.6 A |
|
Total output current |
0.6 |
|
Total output power |
16.8W |
|
Certification & Approvals |
||
Details |
||
Certification |
CE, FCC, IC, EAC, ROHS |
|
Other |
||
Details |
||
Mode button |
Yes |
Products Show
