keepLINK Gigabit Industrial Switch 16 RJ45 Port 2 SFP Slots 100M 1000M POE /POE+ Ethernet Switch Non-management

Regular price: R 18,706.95
Sale price: R 18,706.95
Regular price: ~~R 23,629.95~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

SPECIFICATIONS

Brand Name: keepLiNK

Private Mold: NO

Products Status: Stock

Ports: 18

Function: LACP, POE, QoS, SNMP, Stackable, VLAN Support

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 36G

Brand Name: KeepLiNK

Model Number: KP-9000-65-2GX16TP, KP-9000-65-2GX16GP

Operating temperature: -40°C-75°C

Degree of protection: IP40

Input voltage: DC48-58V(PoE)

Net Weight: 1KG

Dimension: 143X104X48mm( W*L*H)

Installation: DIN rail

Surge protection: 4K~6KV

Chip: Marvell

Product Name: Unmanaged 16ports POE Switch

Anti-static protection: 8KV-15KV

Product Description

Gigabit Industrial Switch 16 RJ45 Port 2 SFP Slots 100M 1000M POE /POE+ Ethernet Switch Non-management

Main Features

DC12V-58(Non-PoE)/DC48~58V(PoE) redundant power supply
Surge protection for power 6KV, for Ethernet port 4KV, anti-static 8KV~15KV
Aluminum body, IP40, -40°C~75°C working temperature.
PoE support 802.3af&at, 250m transmission distance is optional, support short circuit protection when PoE powered.
Support undervoltage alarm(<12V), overvoltage alarm(>58V)
More convenient to use and maintain with DIP Switch: C/D: Reserve; LGY: standard/Nonstandard PoE; VLAN: Port isolation; RST: Remote PD reset

DIP Switch
1 C/D	Reserve
2 LGY	Stand/Non-standard PoE mode
3 VLAN	Port isolation
4 RST	Reset
L2 Switching
Switching capacity	1.4Gbps
Packet forwarding rate	1.0416Mpps
MAC address table	1K
Forwarding delay	<5us
Buffer	512K
MDX/MIDX	Support
Flow control	Support
Jumbo frame	Support 2048 bytes
WatchDog	Support
Electrical Specifications
Input voltage	DC12-58V(Non-PoE), DC48~58V(PoE)
Power consumption	Without PoE<6W, With PoE<186W
Voltage Alarm	Support
Mechanical Structure
Housing	Metal material
Weight	0.5KG around
Mounting	DIN-rail
EMC & Ingress Protection
IP level	IP40
Surge protection of Power	IEC 61000-4-5 Level X (6KV/6KV) (8/20us)
Surge protection of Ethernet port	IEC 61000-4-5 Level 4 (4KV/4KV) (10/700us)
RS	IEC 61000-4-3 Level 3(10V/m)
EFI	IEC 61000-4-4 Level 3(1V/2V)
CS	IEC 61000-4-6 Level 3(10V/m)
PFMF	IEC 61000-4-8 Level 4(30A/m)
DIP	IEC 61000-4-11 Level 3(10V)
ESD	IEC 61000-4-2 Level 4(8K/15K)
Free fall	0.5m
Environment
Operating temperature	-40℃~ +75℃ The device is tested for 4 hours at temperatures in 85℃
Storage temperature	-40℃~ +85℃
Relative humidity	5%~95% (Non-condensing)
Accessories	Equipment, Terminals, Instruction, Certificate, Power adapter(optional)
Dimensions

Packaging & Shipping

Product Information	Fixed port	5*10/100M RJ45, PoE
Packing	Net weight	0.5KG/pcs
	Gross weight	0.8KG/pcs
	Packing list	Switch x1; Phoenix terminal x1; Certificate of inspection x1; Instructions&Warranty card x1

Note: Power adapter and SFP transceivers are not included by default when placing an order, please order separately
Optional models	KP-9000-65-5TP (8*10/100M Rj45, support PoE 802.3af&at)

Every product is unique, just like you. If you're looking for a product that fits the mold of your life, the keepLINK Gigabit Industrial Switch 16 RJ45 Port 2 SFP Slots 100M 1000M POE /POE+ Ethernet Switch Non-management is for you.
