Juniper EX3400 Switch, 24x1G PoE+/4x10G SFP+/2x40G QSFP+ EX3400 Series 24 Ports 10/100/1000BaseT PoE+ Ethernet Network Switch EX3400-24P

Regular price: R 214,770.93
Sale price: R 214,770.93
Regular price: ~~R 279,202.57~~
Unit price: per

Shipping calculated at checkout.

Color

Quantity must be 1 or more

Description

EX3400-24P is a Juniper EX3400 switch with 24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included). EX3400 Ethernet Switches are a cost-effective solution for today’s most demanding converged data, voice, and video enterprise access networks. The compact, fixed-configuration 1U devices offer levels of performance and management previously available only with high-end access switches.

Quick Spec

SKU	EX3400-24P
Ports	24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Backplane speed	160 Gbps
Data rate	288 Gbps
Throughput	214 Mpps (wire speed)
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit

Compare to Similar Items

SKU	EX3400-24T	EX3400-24P	EX3400-48T	EX3400-48P
Ports	24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)	24-port 10/100/1000BASE-T (24 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)	48-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+, 2 x 40GbE QSFP+	48-port 10/100/1000BASE-T (48 PoE+ ports) with 4 SFP+ and 2 QSFP+ uplink ports (optics not included)
Backplane speed	160 Gbps	160 Gbps	160 Gbps	160 Gbps
Data rate	288 Gbps	288 Gbps	336 Gbps	336 Gbps
Throughput	214 Mpps (wire speed)	214 Mpps (wire speed)	250 Mpps (wire speed)	250 Mpps (wire speed)
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit

Specifications

EX3400-24P Specification
Form factor	Fixed 1 U access
Port density	1GbE and SFP+/QSFP+ uplink port options
Wired Assurance	Yes
Campus Fabrics	Virtual Chassis
Cloud Managed	Yes
Dimensions (W x H x D)	17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm)
Dimensions (W x H x D)	1 rack unit
Backplane speed	160 Gbps
Data rate	EX3400-24P/24T/24T-DC: 288 Gbps
Data rate	EX3400-48P/48T: 336 Gbps
Throughput	EX3400-24P/24T/24T-DC: 214 Mpps (wire speed)
Throughput	EX3400-48P/48T: 250 Mpps (wire speed)
Resiliency	Redundant, field-replaceable power supplies
Resiliency	Redundant trunk groups that provide port redundancy and simplify switch configuration
Traffic monitoring	sFlow
Quality-of-service (QoS) queues/port	8 unicast/4 multicast
MAC addresses	32,000
Jumbo frames	9216 bytes
IPv4 unicast/multicast routes	36,000/4,000
IPv6 unicast/multicast routes	18,000/2,000
Number of VLANs	4,096
ARP entries	16,000

The Juniper EX3400 Switch, 24x1G PoE+/4x10G SFP+/2x40G QSFP+ EX3400 Series 24 Ports 10/100/1000BaseT PoE+ Ethernet Network Switch EX3400-24P is evocative, to say the least, but that's why you're drawn to it in the first place.
