Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E
Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E
Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E
  • Load image into Gallery viewer, Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E
  • Load image into Gallery viewer, Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E
  • Load image into Gallery viewer, Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E

Fortinet FG-60E, 10x GE RJ45 ports (including 7x Internal Ports, 2x WAN, 1 DMZ) Max managed FortiAPs VPN Security Firewall FG-60E

R 43,938.04
R 43,938.04
R 61,361.74
Sold out
Shipping calculated at checkout.

Fortinet FG-60E, 10 x GE RJ45 ports (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port) Max managed FortiAPs (Total / Tunnel) 30 / 10 VPN Security Firewall FG-60E

Description

FG-60E, Fortinet FG-60E Firewall, 10 x GE RJ45/Max 30 FortiAPs/7 Internal Ports

FG-60E is the Fortinet NGFW Entry-level Series FortiGate 60E firewall. The FortiGate 60E series offers an excellent Security and SD-WAN solution in a compact fanless desktop form factor for enterprise branch offices and mid-sized businesses.

Quick Spec

SKU

FG-60E

Firewall

3 Gbps

IPS

400 Mbps

NGFW

250 Mbps

Threat Protection

200 Mbps

Interfaces

10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port).

Related Products

Types Model Description
Basic Firewall FG-60E 10 x GE RJ45 ports (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port). Max managed FortiAPs (Total / Tunnel) 30 / 10
1 year bundle FG-60E-BDL-950-12 FG-60E Hardware plus 1 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-60E & FC-10-0060E-950-02-12)
1 year License FC-10-0060E-950-02-12 1 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-60E
3 year bundle FG-60E-BDL-950-36 FG-60E Hardware plus 3 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-60E & FC-10-0060E-950-02-36)
3 year License FC-10-0060E-950-02-36 3 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-60E
5 year bundle FG-60E-BDL-950-60 FG-60E Hardware plus 5 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-60E & FC-10-0060E-950-02-60)
5 year License FC-10-0060E-950-02-60 5 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-60E

Compare to Similar Item

Sku

FG-60E

 FG-61E

Firewall

3 Gbps

3 Gbps

IPS

400 Mbps

400 Mbps

NGFW

250 Mbps

250 Mbps

Threat Protection

200 Mbps

200 Mbps

Interfaces

10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port).

10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port).

Internal Storage

N/A

1x 128 GB SSD



Technical Specifications

FG-60E Specification

Type

FORTIGATE 60E

Hardware Specifications

GE RJ45 WAN / DMZ Ports

2 / 1

GE RJ45 Internal Ports

7

GE RJ45 PoE/+ Ports

-

Wireless Interface

-

USB Ports

1

Console (RJ45)

1

Internal Storage

-

System Performance and Capacity

Firewall Throughput (1518 / 512 / 64 byte UDP packets)

3 / 3 / 3 Gbps

Firewall Latency (64 byte UDP Packets)

3 μs

Firewall Throughput (Packet per Second)

4.5 Mpps

Concurrent Sessions (TCP)

1.3 Million

New Sessions/Second (TCP)

30,000

Firewall Policies

5,000

IPsec VPN Throughput (512 byte)

2 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

200

Client-to-Gateway IPsec VPN Tunnels

500

SSL-VPN Throughput

150 Mbps

Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)

200

SSL Inspection Throughput (IPS, avg. HTTPS)

135 Mbps

SSL Inspection CPS (IPS, avg. HTTPS)

135

SSL Inspection Concurrent Session (IPS, avg. HTTPS)

75,000

Application Control Throughput (HTTP 64K)

650 Mbps

CAPWAP Throughput (HTTP 64K)

890 Mbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of FortiSwitches Supported

8

Maximum Number of FortiAPs (Total / Tunnel Mode)

30 / 10

Maximum Number of FortiTokens

500

Maximum Number of Registered FortiClients

200

High Availability Configurations

Active / Active, Active / Passive, Clustering

System Performance

IPS Throughput

400 Mbps

NGFW Throughput

250 Mbps

Threat Protection Throughput

200 Mbps

Dimensions and Power

Height x Width x Length

1.5 x 8.5 x 6.3 inches

38 x 216 x 160 mm

Form Factor

Desktop

Power Required

100–240V AC, 50–60 Hz

Maximum Current

110V AC / 1.5 A, 220V AC / 0.75 A

Total Available PoE Power Budget

N/A

Power Consumption (Average / Maximum)

11.7 / 14 W

Heat Dissipation

40 BTU/h

Operating Environment and Certifications

Operating Temperature

32–104°F (0–40°C)

Storage Temperature

-31–158°F (-35–70°C)

Humidity

10–90% non-condensing

Noise Level

Fanless 0 dBA

Operating Altitude

Up to 7,400 ft (2,250 m)

Compliance

FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB

Certifications

ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
