NK6000 Series novker NK6000-S3 1310/1550nm SM Optic Fiber OTDR 1xRJ45 port, 3xUSB ports 7 inch TFT-LCD with LED backlight

R 70,188.95
R 70,188.95
R 71,564.95
Sold out
Shipping calculated at checkout.

NK6000 Series novker NK6000-S3 1310/1550nm SM Optic Fiber OTDR 1xRJ45 port, 3xUSB ports 7 inch TFT-LCD with LED backlight

SPECIFICATIONS

High-concerned Chemical: None

Type: Hand Tool Parts

Testing Wavelength: SM-1310/1550nm, MM-850/1300nm

Product name: SM Optic Fiber OTDR

Display: 7 inch TFT-LCD with LED backlight

Interface: 1xRJ45 port, 3xUSB port

Power Supply: 10V(dc), 100V(ac) to 240V(ac)

Battery: 7.4V(dc)/4.4Ah lithium battery

Data Storage: Internal memory: 4GB

Language: English,Spanish and Portuguese etc

Dimension: 253x168x73.6mm

Weight: 1.5kg

Description

NK6000 Series novker NK6000-S3 1310/1550nm SM Optic Fiber

Product Description

NK6000 Series novker NK6000-S3 1310/1550nm SM Optic Fiber OTDR 1xRJ45 port, 3xUSB ports 7 inch TFT-LCD with LED backlight

Optical Time Domain Reflectometer is an intelligent meter of a new generation for the detection of fiber communications systems. With the popularization of optical network construction in cities and countrysides, the measurement of optical network becomes short and disperse. It's economic, having outstanding performance.

model

NK6000

Standard wavelength

1310/1550

Dynamic Range

35/33db

Event dead zone

0.8m

Attenuation dead zone

6m

Ranging accuracy

±(1m+Sampling interval+0.005%x Distance)Does not include refractive index placement error

Highest range resolution

0.05m

Test range

0.4,0.8,1.6,3.2,6.4,16,32,64,128,256,512km

Test pulse width

5,10,30,100,275,500,1000,5000,10000,20000ns

Loss threshold

0.01db

Sampling points

128k

Linearity

0.05dB/dB

Loss resolution

0.001dB

Waveform storage capacity

≥1000

External interface

USB,Min-USB,RJ-45

Optical output interface

FC

VFL

650nm±10nm,≥5mw

Optical power meter

Wavelength range: 1200~1650nm; Power range: -45~+26dBm

Stable light source function

1310/1550nm: -5dBm CW(270Hz, 1K270Hz, 2K270Hz)

Display

5.8inch color TFL-LCD touch screen

Battery

7.4v/5000mAh Li-on battery, Max 12hours

Power supply

Put out: 19V. 1.31A

Adapt to the environment

Operating temperature: -5~+50℃  Storage temperature: -20~+70℃
Relative humidity 0~95% No condensation

Size

215mm*150mm*70mm

Weight

<1.5kg

Language

English(it can be choose)

Fiber Optic Equipment SM MM Mini OTDR Price, Palm FTTH Pon OTDR Tester Machine, FTX OTDR















Imagine if you could be satisfied and content with your purchase. That can very much be your reality with the NK6000 Series novker NK6000-S3 1310/1550nm SM Optic Fiber OTDR 1xRJ45 port, 3xUSB ports 7 inch TFT-LCD with LED backlight.
