Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
  • Load image into Gallery viewer, Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
  • Load image into Gallery viewer, Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
  • Load image into Gallery viewer, Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode
  • Load image into Gallery viewer, Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode

Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode

R 9,683.96
R 9,683.96
R 11,835.95
Sold out
Shipping calculated at checkout.

Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode

SPECIFICATIONS

Adapter Type: SC/LC/FC/E2000

Brand Name: OneFind

Certification: CE

Commodity: WF2116 Optical Light Source

DIY Supplies: Electrical

Fiber Type: SM;MM

Hign-concerned Chemical: None

Model Number: WF2116

Modulation Frequencies: CW,2;270Hz,1KHz,2KHz

Operating Temperature(°C): -10~60

Optical Connector: FC/PC(Other type adapters can be required)

Output Stability: ±0.05dB/15mins; ±0.1dB/ 8hours

Power Supply: Alkaline Battery(3 AA 1.5V batteries); AC Adaptor(8.4V)

Storage Temperature(°C): -25~70

Type: Testers & Tools

Use: FTTH

Warranty Time: 1 Year

wavelength: 1310/1550nm standard or customized

Product Description

Optical Light Source is one of the latest self developed test instrument.It can provide 2 to 5 wavelength output according to the specific requirements including the 650nm red source, 1310/1550nm wavelength for the single mode fiber and 850/1300nm wavelength for the multimode fiber or other wavelengths according to customer needs. Together with optical power meter, it acts as a perfect solution for the fiber optic network work.

Features
● Tone generation, 270HZ, 1KHZ,2KHZ;
● Output power value is shown on LCD display;
● Intelligent backlight control (light intensity can be adjusted properly according to ambient light, which greatly reduced power consumption);
● AA alkaline for power supply;
● Low battery indication.

Specification

Type

WF2116

WF2116-3



 WF2116-4 customized

Wavelengths(nm)

1310/1550

1310/1550/1490

 1310/1550/1490 /1625nm

850/1300/1310/1500nm



850/1300/1310/1500

Emitter Type

FP-LD,LED or others please specify



Typical Output Power

-7dBm for LD, -20dBm for LED



Spectral Width(nm)

≤10



Output Stability

±0.05dB/15mins; ±0.1dB/ 8hours



Modulation Frequencies

CW,270Hz,1KHz,2KHz



Optical Connector

FC/PC(or FC/SC/ST interchangeable connectors)



Power Supply

Alkaline Battery(3 AA 1.5V batteries)



Battery Operating

45



Operating

-10~60



Storage

-25~70



Dimension(mm)

200 X90 X50



Weight (g)

285



Packing & Delivery

The Fiber Optical Light Source WF2116 laser Source, 1310/1550nm wavelength for single mode and 850/1300nm wavelength for the multimode is a sensational customer favorite, and we hope you like it just as much.
