SRNE solar storage battery 5kw 10kw 15kw energy storage system battery
SPECIFICATIONS
- High-concerned Chemical: None
- DIY Supplies: Electrical
- Battery Type: LiFePO4, LiFePO4/Lithium Ion
- Model Number: SR-EOS10B
- Brand Name: SRNE
- Product name: Lifepo4 battery Solar Energy Storage System Battery With Smart BMS
- output voltage: 120/240Vac
- Output frequency: 60Hz/50Hz
- Type: Off-grid System AC
- Load Power (W): 5KW 10KW 15KW 20KW
- Application: Energy Storage System
- Function: Power Support
- length of work: 24h
- Warranty: 5years
- Inverter Type: Pure Sine Wave
- Power Source: Solar Panel
- Controller Type: MPPT
Product Description
SR-EOS Energy Storage Battery
SR-EOV48 Series

Intelligence
* Support Wifi and BT view real-time data through APP
* Large LCD screen with real-time data
* Large LCD screen with real-time data
Easy to install
* Supports wall or floor mounting
* Plug-and-play,Wiring can be done from either side
* Plug-and-play,Wiring can be done from either side
User friendly
* Get started quickly and use it instantly
* Min. width of just 19.1cm, saving space in the home
* Min. width of just 19.1cm, saving space in the home
Easy to upscale
* Compatible with many brands of inverter protocols
* Up to 9 in parallel connection, expand to 92.16kWh
* Up to 9 in parallel connection, expand to 92.16kWh
Safety
* High quality lithium iron phosphate cells
* Proven Li-ion battery management solution
* Proven Li-ion battery management solution
Specification
MODEL
|
SR-EOS10B
|
MAIN INFO
|
|
Rated Voltage
|
51.2V
|
Rated Capacity
|
200Ah
|
Battery Power
|
10.24kWh
|
Battery Type
|
LFP
|
Crycling Lifespan
|
6000 Cycles
|
Lifetime
|
20 Years
|
Max. Parallel Capacity
|
9
|
CHARGE&DISCHRAGE
|
|
Max. Charging Voltage
|
57.6V
|
Over Discharging Voltage
|
44.8V
|
Max. Charging Current
|
150A
|
Peak Charging Current
|
200A (3s)
|
Max. Discharging Current
|
200A
|
Peak Discharging Current
|
220A (3s)
|
GENERAL
|
|
Weight
|
88kg,(194lb)
|
Dimension(L*W*H)
|
1014*620*191mm(3*2*0.6ft)
|
Communication
|
CAN / RS485 / USB / WiFi / Bluetooth
|
Storage Condition
|
6 months @25℃;3 months @35℃;1 months @45℃
|
Charging Temp. Range
|
0~45℃(32~113℉)
|
Discharging Temp. Range
|
-10~45℃(14~113℉)
|
Cooling Method
|
Neutral Cooling
|
Protection Grade
|
IP65
|
STANDARD
|
|
Transportation
|
UN38.3,MSDS
|
Safety
|
EN55032,EN55024,EN61000-3-2,EN61000-3-3
|
Detailed Images




The SRNE Smart LiFePO4 Battery 48Vdc 51.2V 5kwh 10kwh 15kwh 20kwh 6000 Cycle Lithium Battery with Hybrid Off Grid Solar Inverter is the product you didn't think you need, but once you have it, something you won't want to live without.
