Synology DS1522+ DiskStation 5 Bay NAS - Quad Core 2.0GHz, 8GB DDR4 RAM, Up to 15-Bay Support

*Order on Demand - Available on Backorder (2-6 Weeks)



Description

Synology DS1522+

Synology DiskStation 5 Bay NAS (up to 15-bay), Quad Core 2.0GHz, 8GB DDR4 RAM (non-ECC), 1x m.2 SSD Slot, 4x Gigabit Ethernet LAN, 2x USB3.0, 2x eSATA

Flexible data management for homes and small business

The 5-bay Synology DiskStation DS1522+ is easy to scale and expand as your needs change, with optional support for up to 15 drives, 10GbE networking, and NVMe SSD caching. Powered by Synology DiskStation Manager (DSM), it offers a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.

Simply faster

DS1522+ can handle more demanding application workloads and a greater number of concurrent users compared to prior-generation systems. Experience faster file indexing in Synology Drive, photo organization in Photos, and concurrent file transfers.

Flexible networking options

Reduce transfer times with the DS1522+, designed to accelerate your workloads. Easily add faster networking and NVMe drives to further boost performance.

Everything you need for your home office

Make the most of high-performance networking and file access without taking up unnecessary space. DS1522+ comes equipped with 5 bays and can scale up to 15 bays with 2 DX517 expansion units as your data needs grow.

Store, share, and protect

Manage all your documents, photos, and other files, back up applications and devices, or protect your assets with professional video surveillance.

Hardware Specifications
CPU
CPU Model AMD Ryzen R1600
CPU Quantity 1
CPU Core 2
CPU Architecture 64-bit
CPU Frequency 2.6 (base) / 3.1 (turbo) GHz
Hardware Encryption Engine
Memory
System Memory 8 GB DDR4 ECC SODIMM
Memory Module Pre-installed 8 GB (8 GB x 1)
Total Memory Slots 2
Maximum Memory Capacity 32 GB (16 GB x 2)
Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For multi-module memory configurations, all modules must be identical and share the same model number.
Storage
Drive Bays 5
Maximum Drive Bays with Expansion Unit 15 (DX517 x 2)
M.2 Drive Slots 2 (NVMe)
Drive Type
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe SSD
Hot Swappable Drive*
Notes The hot swappable drive feature is not supported by M.2 SSD slots.
External Ports
RJ-45 1GbE LAN Port 4
USB 3.2 Gen 1 Port 2
Expansion Port 2
Expansion Port Type eSATA
Notes MTU value of 1GbE LAN port has a limit of 1500.
PCIe
PCIe Expansion 1 x Gen3 x2 network upgrade slot
Appearance
Size (Height x Width x Depth) 166 mm x 230 mm x 223 mm
Weight 2.7 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 22.90 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 120 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 52.06 watts (Access)
16.71 watts (HDD Hibernation)
British Thermal Unit 177.64 BTU/hr (Access)
57.02 BTU/hr (HDD Hibernation)
Notes

Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • BIS
Warranty
3-year hardware warranty, extendable to 5 years with Extended Warranty Plus
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt.
  • Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions.
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • DDR4 ECC SODIMM: D4ES02-8G/D4ES01-16G
  • Expansion Units: DX517
  • Enterprise Series 3.5" SATA HDD: HAT5300 Series
  • Plus Series 3.5" SATA HDD: HAT3300 Series
  • Enterprise Series 2.5" SATA SSD: SAT5200 Series
  • Enterprise Series M.2 2280 NVMe SSD: SNV3400 Series
  • 10GbE Network Upgrade Module: E10G22-T1-Mini
