UNV - H.265 - 4MP LightHunter Dual-spectrum Thermal Network Turret Camera - smoke, fire & Temperature

Description

TIC3612SA-F3-4F4AC-I1

Thermal & Optical Dual-spectrum Turret Network Camera
• Thermal & optical dual-spectrum image, dual video with single IP address, adaptable to various scenes
• 1/2.8" target surface, high sensitivity sensor, suitable for starlight monitoring
• Thermal module supports reliable fire detection and fire shield area
• Thermal module supports temperature detection and cold&hot spot tracking, which highlights abnormal temperatures and links to alarm
• Thermal & optical dual-spectrum smart intrusion prevention can be enabled simultaneously : cross line, enter area, leave area, intrusion
• Optical module supports smog recognition, which can help with fire alarm reconfirmation
• Supports picture-in-picture mode, real-time contrast live, more convenient and clear
• Supports audio and light alarm, with red and blue warning lights built in
• Ultra 265, H.265, H.264, MJPEG
• Max 2688 × 1520@30 fps in the optical module and max 960P@30 fps in the thermal module
• DC 12 V ± 25% or PoE power supply
• Alarm 2 in and 2 out, audio 1 in and 1 out, micro SD, up to 512 G

SKU: UN-IPC3A-THERMAL
Warranty: 2 Year
Manufacturer SKU: TIC3612SA-F3-4F4AC-I1

Categories:
Surveillance, IP Cameras, Dome Camera
Brand: Uniview

Features

Uniview SIP, 12V DC 24V AC, PoE, IP67, IR 50m, 3.2mm Thermal, 4mm Optical, SD Slot 256 GB, Built in Mic

Specifications

TIC3612SA-F3-4F4AC-I1
Channel
Camera
Original Resolution N/A 256 × 192
Sensor 1/2.8" CMOS Vanadium oxide uncooled focal plane arrays
Min. Illumination Colour: 0.003 lux (F1.6, AGC ON)
B/W: 0.002lux(F1.6,AGC ON)
0 lux with IR		 N/A
Day/Night IR-cut filter with auto switch (ICR) N/A
Pixel Size N/A 12 um
NETD < 50 mk@F1.0@25 ℃ < 50 mk@F1.0@25 ℃
Shutter Auto/Manual, 1 to 1/100000 s Auto/Manual, 1 to 1/100000 s
WDR 120 dB 120 dB
S/N >56 dB >56 dB
Lens
Focal Length 4mm 3 mm
Iris F1.6 F1.0
Field of View (H) 72.9° 58.0°
Field of View (V) 44.4° 42.5°
Field of View (D) 89.8° 72°
DORI
DORI Distance (Detect) 90.0m(295.3ft) N/A
DORI Distance (Observe) 36.0m(118.1ft) N/A
DORI Distance (Recognize) 18.0m(59.1ft) N/A
DORI Distance (Identify) 9.0m(29.5ft) N/A
Illuminator
Wavelength 750 nm N/A
Illumination Distance (IR) 30m N/A
Light On/Off Control Auto/Manual N/A
Video
Frame Rate 4MP(2688*1520), Max 30fps 960P(1280*960), Max 30fps
Video Compression Ultra 265, H.265, H.264, MJPEG Ultra 265, H.265, H.264, MJPEG
Video Bit Rate 128 Kbps to 16 Mbps 128 Kbps to 16 Mbps
U-code Support Support
ROI Support Support
Video Stream Triple streams Triple streams
OSD Up to 8 OSDs Up to 8 OSDs
Privacy Mask Up to 8 areas (8 blacks/ 8 mosaics) N/A
White Balance Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 N/A
Digital Noise Reduction 2D/3D DNR 2D/3D DNR
Flip Normal, Flip vertical, Flip horizontal, 180°, 90° Clockwise, 90° Anti-clockwise Normal, Flip vertical, Flip horizontal, 180°, 90° Clockwise, 90° Anti-clockwise
HLC Support N/A
BLC Support N/A
Defog Digital defog N/A
Palette N/A puce, rain, fusion, mazarine, medical, arctic, lava, color 2, color 1, green hot, red hot, black hot, ice hot, depict hot, rainbow 3, rainbow 2, rainbow 1, hot iron, iron oxide red, white hot
Intelligent
Smart Intrusion Prevention Cross line detection, intrusion detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human and vehicle)
Smoke Detection Support N/A
Temperature Measurement Accuracy ±8 ℃ (±14.4 ℉) or ±8% (whichever is greater)
Temperature Range Selectable between -20 ℃ to 150 ℃ (-4 ℉ to 302 ℉) and 100 ℃ to 550 ℃ (212 ℉ to 1022 ℉)
Events
Fire Detection N/A Support
Basic Detection Motion detection, Tampering alarm, Audio detection N/A
General Function Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output
Audio
Audio Compression G.711U, G.711A G.711U, G.711A
Audio Bitrate 128 Kbps 128 Kbps
Two-way Audio Support Support
Suppression Support Support
Sampling Rate 16KHZ 16KHZ
Storage
Edge Storage Micro SD, up to 512 GB Micro SD, up to 512 GB
Network Storage ANR ANR
The UNV H.265 4MP LightHunter Dual-spectrum Thermal Network Turret Camera, smoke, fire, Temp, Uniview SIP, 12V DC 24V AC, PoE, IP67, IR 50m, 3.2mm Thermal is the product you didn't think you need, but once you have it, something you won't want to live without.
