WavLink AC600 Router Outdoor Wifi Antenna Mesh, 4 Band Weatherproof Long Range Router Mesh long range ac600 external Wifi router

WavLink AC600 Router Outdoor Wifi Antenna Mesh, 4 Band Weatherproof Long Range Router Mesh long range ac600 external Wifi router

SPECIFICATIONS

Brand Name: eOQO

Item Type: wifi

Hign-concerned Chemical: none

Certification: CE

Certification: FCC

Frequency: 2.4GHz & 5GHz, speed up to 1,200 Mbps

Antennas: 4x 7dBi omni Antennas

Operation Modes: Router,AP,Mesh Extender

Weatherproof Case: 15KV ESD and 4KV Lightning Protection

Security: WPA2-PSK,WPA 2/ WPA 3 Mix

LEDs: 7x Status LED Indicators

Power Adapter: 100~ 240V/50~60Hz; DC 24V (Passive PoE)

AC1200

WAVLINK AC1200 High Power Outdoor Weatherproof WiFi Range Extender/Wireless Access Point/mesh agent with Passive POE, Dual Band 2.4GHz 300Mbps+5.8 GHz 867Mbps, 4x7dBi Detachable Omni Directional Antennas, Mesh Technology Supported, No WiFi Dead Zones for Working from Home

Description:

WAVLINK Outdoor WIFI Extender- Bringing Technology to Life

The WN572HP3 is designed to provide for an excellent wireless network connection from long distance, definitely your worthy choice.

Dual Bands WiFi Repeater

With combined wireless speeds of up to 2.4GHz 300Mbps or 5GHz 867Mbps, simple tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth-intensive tasks like online gaming or HD video streaming can be processed by the 5GHz.

Multiple Operation Modes

Mesh Extender Mode: Co-create a larger wireless network coverage with Wavlink mesh supported routers and share signal to multiple WiFi devices.

AP Mode: Convert a wired network to a wireless network, which allows you connect laptops, tablets, phones or other WiFi devices.

Repeater Mode: Extend WiFi coverage of an existing wireless network.

Withstand Harsh Climates

An IP65-rated weatherproof housing that ensures the 572HP3 continued operation on harsh outdoor environments or in climates of extreme cold, heat or continuous moisture. Withstanding broad ranges of humidity and temperature (-30°C~70°C) (-22°F~158°F). Build in lightning arrester (15kV ESD), 4KV lightning protection.

Note: The PoE part of the router is not waterproof.

Applicable for Large-coverage

Extend the network over long-distances (max 200 meters) with high gain 4x7dBi antennas that deliver a stable and fast network connectivity to large yards and patios. So, it can boost Wi-Fi coverage up to max A=πr^2(r=200m)= 125,600m^2(1350,000 sq.ft), which is over 135 times larger than others' only 10,000 sq.ft coverage!

Strengthening Waterproof Parts

In order to avoid the water leakage issue the latest version 572HP3 has specially improved the key parts, coated with waterproof glue, greatly strengthening the waterproof protection.

Installation note:

- Select the wireless network with a signal strength greater than 70% to get the most reliable connection.

- The outdoor antennas should be installed at a height of 2 meters above the roof or in a high open place for better reception.

Specifications:

Frequency: 2.4GHz & 5GHz, speed up to 1,200 Mbps

Interfaces: 1x 10/100/1,000Mbps LAN; 1x 10/100/1,000Mbps WAN

Antennas: 4x 7dBi omni Antennas

Operation modes: Repeater, AP, Mesh Extender

Weatherproof case: 15KV ESD and 4KV Lightning Protection

Security: WPA2-PSK,WPA 2/ WPA 3 Mix

LEDs: 7x Status LED Indicators

Power adapter: 100~ 240V/50~60Hz; DC 24V (Passive PoE)

AX1800

WAVLINK WiFi6 Outdoor Mesh Router/AP/Repeater, Dual Band 2.4G+5G AX1800 Long Range Outdoor WiFi Mesh Extender with PoE/4x8dBi High-gain Antennas/IP67 Weatherproof Enclosure/Signal Booster Amplifier

Description:

WAVLINK Professional Outdoor Router/AP/Repeater, Enjoy Super-Speed WiFi6 Anytime & Anywhere

WN573HX1 is a high-performance outdoor router/AP/repeater specially designed for outdoor use: Robust weatherproof case and 15kV ESD protection ensure continuous operation and stable connection under harsh outdoor conditions; The 4 x 8dBi omnidirectional fiberglass tube antennas feature high strength and high precision, a long service life and excellent wireless performance; Supports IEEE 802.11 ax/ac/a/n/g/b standards, and provides blazing-fast Internet speeds of 1800Mbps (2.4GHz 574Mbps+5GHz 1201Mbps); Supports MU-MIMO and Beamforming technology, allowing up to 128 devices to be connected simultaneously in a wider range.

How to install antennas and Ethernet cable?

①Pass the RJ45 cable through the waterproof connector cover.

②Screw the waterproof seal into the waterproof connector bracket.

③Pass the RJ45 cable through the waterproof connector bracket, and screw the waterproof connector bracket into the cover.

④Put the waterproof sealing ring on the waterproof connector bracket.

⑤Connect the RJ45 cable to WAN/LAN port.

⑥Screw the connecting cable into the 2.4G and 5G antenna connector and screw up the connector.

Note: The PoE converter is not waterproof, please install it indoors. Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.

How to install the product on a column?

①Stick two silicone pads on the bracket and post respectively.

②Thread the cable ties through the fixing point of the bracket.

③Fix the product to the post with cable ties.

Fiberglass Tube High Gain Antennas

4 x 8dBi omnidirectional antennas are covered by strong fiberglass tube, expanding signal coverage and withstanding harsh conditions, providing superior WiFi performance and longer service life.

IP67 Waterproof Enclosure

Equipped with an IP67 enclosure with excellent dustproof and waterproof capabilities, this product can operate normally in rainy days, snowy days, thunderstorms, sandstorms and other severe weather.

PoE Power Supply

Both active and passive PoE are supported. You can install the corresponding PoE converter according to your needs. Passive PoE converter included.

574Mbps on 2.4G & 1201Mbps on 5G

Dual band AX1800 provides smoother online surfing experience and stronger anti-interference capability. 2.4G band is commendable for web browsing and social media use, while 5G band is ideal for video streaming or gaming.

High Power Amplifiers

Dual integrated signal boosters efficiently strengthen the wireless performance. The PA(power amplifier) increases the power output while the LNA(low-noise amplifier) minimizes additional noises and increases the wireless signal.

Advanced WiFi Safeguard

WPA2-PSK & WPA2/WPA3-MIX wireless security protocols are supported, fully protecting your private information and keeping your WiFi connection secure at all times.

Technical Specifications:

- Model: WL-WN573HX1

- Product Size(without antennas): 24x24x7cm/9.4x9.4x2.8in

- PoE Converter Size: 4.4x3.7x2.2cm/1.7x1.5x0.9in

- Length: Antennas - 40cm/15.7in; Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in

- Product Weight(without antennas): 1109g/39.1oz

- Standard: IEEE 802.11 ax/ac/a/n/g/b

- Frequency Band/Speed: 2.4GHz(574Mbps)+5GHz(1201Mbps)

- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX

- Antennas: 4 x 8dBi Omnidirectional Antennas

- PAIR/RESET LED: Blue

- PoE Converter Status LED: Green

Features:

- Robust weatherproof case, IP67 waterproof rating and built-in lightning arrester (15kV ESD) withstands harsh outdoor conditions.

- Supports 802.3 AT/AF active PoE and passive PoE to supply power.

- Fiberlass tube antennas for high precision, corrosion resistance, long life, strong wind resistance.

- 4x8dBi detachable omnidirectional external antennas provide excellent wireless performance.

- Supports dual band(2.4G 573Mbps+5G 1201Mbps) with combined speeds of up to 1800Mbps.

- Mesh technology makes you enjoy seamless roaming throughout the house with a single network name and password.

- Complies with IEEE 802.11 ax/ac/a/n/g/b standards.

- Supports Mesh/AP/Router/Repeater/AP+Repeater modes.

- Encryption type:WPA2-PSK, WPA3/WPA2-MIX.

Notes:

①The PoE converter is not waterproof, please install it indoors.

②Make sure your Ethernet cable is CAT5e or above certified and shorter than 100m/328ft.

③Install the product 2-3 meters above the ground for better performance.

④Under the mesh mode, WN573HX1 ONLY supports interconnection with WN531AX2, WN583AX1 and WN573HX1.
