UOTEK 8G+2XG 10 Ports Unmanaged POE Industrial Ethernet Switch 10/100/1000M DIN-rail Switch IP40 Protection UT-60208G-8GT-2XGP-POE

Regular price: R 23,285.58
Sale price: R 23,285.58
Regular price: ~~R 31,846.46~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

SPECIFICATIONS

Brand Name: UOTEK

Cache size: 2Mb

High-concerned chemical: None

IP rating: IP40

MAC address size: 16K

Max. frame length: 10KB

Mode: Full-duplex or half-duplex mode, auto negotiation

Operating temperature: -40 ~ 75°C

Relative humidity: 0~95% (non-condensing)

Storage temperature: -40 ~ 85°C

Switching bandwidth: 56G

Transmission mode: Store-and-forward

Brand Name: UOTEK

Communication Mode: Full-Duplex & Half-Duplex

Model Number: UT-60208G-8GT-2XGP-POE

Ports: 10

Products Status: Stock

Transmission Rate: 10/100/1000Mbps

Description:

UOTEK 8G+2XG 10 Ports Unmanaged POE Ethernet Switch 10/100/1000M DIN-rail Switch with IP40 Protection UT-60208G-8GT-2XGP-POE

UT-60208G-8GT-2XGP-POE is a 10G unmanaged industrial Ethernet switch. It provides 8 Gigabit POE ports, 2 10G SFP+ ports, plug & play. Each POE port can provide with the connected device(camera, access point, IP phone) up to 30W power while the external power is limited.
It adopts low power consumption, fan-less design; meanwhile, the operating temperature range is from -40 ~ 75°C; With good EMC electromagnetic compatibility, it ensures the device working stable in harsh industrial environments. It provides a safe and reliable solution for quickly and stably connecting network in various industrial applications such as industrial automation, intelligent transportation, and video surveillance.

Characteristics

> Full-duplex or half-duplex mode, auto-negotiation
> 10/100/1000Mbps, auto-MDI/MDI-X
> IP40 protection
> Relay output alarm function
> Redundant dual power input, overload and reverse polarity protection
> Wide operating temperature: -40~75°C

Parameters

Standard
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3ae, IEEE802.3af/at
Interface
Fiber port: 10Gbps SFP+ (10 Gigabit SFP port)
RJ-45 port: 10/100/1000Base-T, auto-MDI/MDI-X
POE power: +(1, 2) pins, -(3,6) pins
LED indicator
power indicator, network indicator, alarm indicator, 10G SFP+ indicator, POE indicator
Transmission Distance
Cat.5e: 100m
Optical module
Single-mode: 1,310nm 20/40/60Km
1,550nm 80/100/120Km
Multi-mode: 1,310nm 2Km
Switch property
1000M forwarding rate: 1,488,095pps
10G forwarding rate: 14,881,000pps
Transmission mode: store and forward
MAC address size: 16K
Cache size: 2Mb
Switching bandwidth: 56G
Max. frame length: 10KB
Power requirement
Input voltage: 48VDC(46~57VDC), support dual power redundant input, reverse polarity protection
Power consumption
Single POE port up to 30W, total power consumption not exceed to 150W
Mechanical characteristic
IP rating: IP40
Installation: DIN-Rail/wall mounting
Mechanical dimension
Device size (W x H x D): 150mm x 47.6mm x 100mm
Package size: 250mm x 205mm x 108mm
Weight: 900g
Operating environment
Operating temperature: -40 ~ 75°C
Storage temperature: -40 ~ 85°C
Relative humidity: 0~95% (non-condensing)
Industrial standard
EMI: FCC Part 15, CISPR (EN55022) class A
EMS:
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC(EN)61000-4-8
IEC 60068-2-27(Shock)
IEC 60068-2-32(Freefall)

The UOTEK 8G+2XG 10 Ports Unmanaged POE Industrial Ethernet Switch 10/100/1000M DIN-rail Switch IP40 Protection UT-60208G-8GT-2XGP-POE destined to impress, and priced at only R 23,285.58, for a limited time.
