UOTEK 10M/100M Ethernet to 4 Ports CANBUS-FD Protocol Converter CAN2.0 CANFD Protocols RJ-45 Adapter Level 3 12-36V DC UT-6504-FD

SPECIFICATIONS

Brand Name: UOTEK

ESD Protection: Level 3

High-concerned chemical: None

Isolation voltage: 1000VDC

Model Number: UT-6504-FD

OEM/ODM: Support

Operating current: ≤ 200mA@12V

Operating temperature: -40~85°C

Operating voltage: 12-36V DC

Product Name: Ethernet to 4-port CANBUS-FD Protocol Converter

Support protocol: CAN2.0, CANFD protocols

Surge Protection: Power Port: Level 3, Network Port: Level 3

Description

UOTEK 10M/100M Ethernet to 4 Ports CANBUS-FD Protocol Converter CAN2.0 CANFD Protocols RJ-45 Adapter UT-6504-FD

Accept Customization/QC Pass/ Fast Shipping

UT-6504-FD is a high-performance CAN-bus communication converter with integrated 4 CAN-FD interfaces and 1 network port. The converter supports interconnection between 10M/100M Ethernet networks and CAN-bus communication rates from 5Kbps to 5Mbps, further expanding the application range of CAN-bus and Ethernet. UT-6504-FD converter provides a web configuration interface, allowing users to flexibly set the operating parameters. It features an industrial-grade high-standard design with isolation between communication interfaces and the system, providing certain anti-interference and surge protection capabilities. It is widely used in industrial control and data communication systems.

Parameters:

> Achieves bidirectional data transfer between CAN-bus and the network
> Supports CAN2.0, CANFD protocols
> Integrated 4 CAN-bus-FD communication interfaces, supporting communication rates from 5Kbps to 5Mbps
> Integrated 1 10M/100M Ethernet interface
> Operating Voltage: 12-36V DC
> Operating Current: ≤ 200mA@12V
> Operating Temperature: -40~+85°C
> Storage Temperature: -40~+85°C
> Operating Humidity: 5~95% (non-condensing)
> Storage Humidity: 5~95% (non-condensing)
> Isolation Voltage: 1000VDC
> ESD Protection: Level 3.
> Surge Protection: Power Port: Level 3, Network Port: Level 3
> EN 61000-4-3 CS Power 3V/m, Network 3V/m
> EN 61000-4-6 RS 10V/m
> EMI RE, CE: EN55032 classA
