UOTEK 1000M Gigabit 10-Port Unmanaged Ethernet Switch Industrial DIN-rail Switch with Telecom Standards UT-60208F-8T-2GP-MNF

Regular price: R 13,016.58
Sale price: R 13,016.58
Regular price: ~~R 16,955.81~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

SPECIFICATIONS

1000M ports: 1,488,095pps

100M ports: 148,810pps

Brand Name: NONE

Full load: <15W

High-concerned chemical: None

IP rating: IP40

MAC address size: 8K

Operating Temperature: -40℃~85℃

Supports: full-duplex or half-duplex, auto negotiation

Switching bandwidth: 5.6G

Transmission mode: store and forward

Voltage input: 12/24/48VDC(10.8~52.8VDC)

Brand Name: UOTEK

Communication Mode: Full-Duplex & Half-Duplex

Model Number: UT-60208F-8T-2GP-MNF

Ports: 10

Products Status: Stock

Transmission Rate: 10/100/1000Mbps

Description

UOTEK 1000M Gigabit 10 -Port Unmanaged Ethernet Switch Industrial DIN-rail Switch with Telecom Standards UT-60208F-8T-2GP-MNF

UT-60208F series are unmanaged industrial Ethernet switches. It supports up to 10 ports, which included 2 Gigabit fiber ports. This switch is low power consumption; the fanless design prevents it from noise interference; the operating temperature range is from -40~85°C. These make it provides safe and reliable solution for industrial automation, intelligent transportation, video monitoring, and other industrial application networking.

Remarks:
1. Single-mode dual-fiber SC port is a standard configuration for 100M optic ports of products above mentioned, with optional ST/FC
2. The suffix “F” in “MNF” means 12/24/48VDC 10.8~52.8VDC Power input;
The suffix “D” in “MND” means 110/220VAC/DC 88~264VAC/DC dual Power input

Characteristics

> Supports full-duplex or half-duplex, auto negotiation
> Supports 10/100Base-T(X), auto detection, auto MDI/MDI-X
> Built-in store-and-forward, 8k buffer
> Operating temperature: -40~85°C
> IP rating: IP40
> Relay output auto alarm function
> Non-polarity, overload and reverse polarity protection
> Compatible with Telecom standards, MTBF>300,000 hours

Parameters

>>Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z

>>Ports
Fiber port: 100Base-FX(SC/FC/ST)
1000Base-X(SC/FC/ST)
RJ-45 port: 10/100Base-T(X), auto MDI/MDI-X

>>Transmission Distance
Cat.5e: 100m
Fiber Patch Cord
Single-mode: 1,310nm 20/40/60Km
1,550nm 20/40/60/80/100/120Km
Multi-mode: 1,310nm 2Km

>>Switching Performance
Forwarding rate:
100M ports: 148,810pps
1000M ports: 1,488,095pps
Transmission mode: Store-and-forward
MAC address buffer: 8K
Switching bandwidth: 5.6G

>>Power Requirement
Voltage input: with optional 12/24/48VDC(10.8~52.8VDC) and 110/220VAC(88~264VAC)/50-60Hz or 110/220VDC(88~264VDC)

>>Power Consumption
Full load: <15W

>>Mechanical Characteristics
IP rating: IP40
Installation: DIN-Rail

>>Dimension
Size(W×H×D): 150 mm×70mm×100mm

>>Environment
Operating temperature: -40~85°C
Storage temperature: -40~85°C
Relative humidity: 0~95%(non-condensing)

>>Industrial Standards
EMI: FCC Part 15, CISPR (EN55022) class A
EMS:
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC 60068-2-27(Shock)
IEC 60068-2-32(Freefall)

The UOTEK 1000M Gigabit 10-Port Unmanaged Ethernet Switch Industrial DIN-rail Switch with Telecom Standards UT-60208F-8T-2GP-MNF is the yin, to your yang. You've found what you're looking for.
