UOTEK 10/100M 2 Ethernet Ports 1 Optic Fiber Port Switch Industrial Grade HIgh Quality Fiber Optic Transceiver IP40 DC12/24/48V UT-2602

Regular price: R 5,858.06
Sale price: R 5,858.06
Regular price: ~~R 7,263.99~~
Unit price: per

Shipping calculated at checkout.

Color

Quantity must be 1 or more

SPECIFICATIONS

Brand Name: UOTEK

Built-in: store-and-forward

High-concerned chemical: None

IP rating: IP40

Input voltage: DC12/24/48V

Model Number: UT-2602

Operating temperature: -40℃~85℃

Optical Connector: SC,ST, FC

Overload protection: Yes

Protocol: support multiple protocols

Reverse polarity protection: Yes

Standards: IEEE 802.3 IEEE 802.3u

Terminal block: 1 pluggable 3-pin terminal block

Type: Fiber Optic Media Converter

Description

UOTEK 10/100M 2 Ethernet Ports 1 Optic Fiber Port Switch Industrial Grade HIgh Quality Fiber Optic Transceiver UT-2602

UT-2602 is an industrial Ethernet switch with 1 fiber port and 2 10/100Mbps RJ-45 ports. It is your best choice for smart building or fiber to desktop solution. 10/100Mbps, auto negotiation; it extends the transmission distance from 100m to thousands meters, easily to make the connection among master servers, repeaters, hubs, terminals. It adopts industrial design, fanless, low power consumption, and great EMC protection. The working temperature range of UT-2602 is -40~85°C. The reverse polarity protection prevents from device burnt. It supports industrial standard DIN-Rail installation or wall-mounted installation, which meets the different industrial network requirements. UT-2602 is widely used in the field of power, rail transit, mine, and other industrial automation fields.

> 1x 100Base-FX fiber port & 2x 10/100Base-T(X) Ethernet ports
> Adopts optoelectronic integration module,ensures reliable transmission, long working life
> Supports full-duplex or half-duplex mode, auto negotiation
> 10/100Mbps, auto negotiation
> Auto MDI/MDI-X
> Built-in store-and-forward, supports multiple protocols
> Telecom standards, MTBF>400,000 hours
> Working power: DC12/24/48V
> SC connector with optional ST, FC, LC

>>Standards
IEEE 802.3
IEEE 802.3u
>>Ports
Fiber port: 1x 100Base-FX port(with optional SC, ST, FC & LC)
RJ45 port: 2x 10/100Base-T(X) port, auto detection, full/half-duplex, auto MDI/MDI-X
LED indicators: PWR, FDX

>>Fiber-optic feature

Transmission fiber
Multi-mode: 50/125, 62.5/125
Single-mode: 8.3/125, 8.7/125, 9/125, 10/125μm
Transmission distance
Multi-mode: 2km
Single-mode: 20km, with optional 40Km, 60Km, 80km, 120km
UTP5: 100m
>>Power requirement
Input voltage: DC12/24/48V
Terminal block: 1 pluggable 3-pin terminal block
Overload protection: Yes
Reverse polarity protection: Yes
>>Mechanical characteristics
IP rating: IP40
Installation: DIN-Rail
Dimension(W x H x D): 100mm×35mm×80.5mm
>>Environment
Operating temperature: -40~85°C
Storage temperature: -40~85°C
Relative humidity: 5~95% (non-condensing)
>>Industrial standards
EMI: FCC Part 15 Subpart B class A N55022 class A
EMS:
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC(EN)61000-4-8
IEC 60068-2-27(Shock)

The UOTEK 10/100M 2 Ethernet Ports 1 Optic Fiber Port Switch Industrial Grade HIgh Quality Fiber Optic Transceiver IP40 DC12/24/48V UT-2602 destined to impress, and priced at only R 5,858.06, for a limited time.
