ONV Industrial POE Switch 802.3 Af/at 48V 4/8/16/24 x 10/100/1000Mbps PoE Port with 120W/240w Power Supply, 16G switching capacity

R 3,335.77
R 3,335.77
R 3,942.28
Sold out
Shipping calculated at checkout.

ONV Industrial POE Switch 802.3 Af/at 48V 4/8/16/24 x 10/100/1000Mbps PoE Port with 120W/240w Power Supply, 16G switching capacity

SPECIFICATIONS

Buffer Memory: 2M

Certification: CE RoHS FCC

Forwarding Mode: Store and Forward(Full Wire Speed)

Max Power Per Port: 30W

Operation TEMP / Humidity: -40~+80°C;5%~90% RH Non condensing

POE port: Port 1 to 4 IEEE802.3af/at @POE

PoE Standard: IEEE802.3af/at

Product Name: industrial poe switch

Warranty: 5 years, lifelong maintenance.

Brand Name: ONV, OEM/ODM accepted

Communication mode: Full-Duplex & Half-Duplex

Function: LACP, POE, QoS, SNMP, VLAN Support

Model Numbers: IPS33064P / IPS33064PF / IPS33064PFM / IPS33108P / IPS33108PF / IPS33108PFM

Ports: ≤ 8

Private Mold: Yes

Products status: Stock

Switch Capacity: 16G

Transmission rate: 10/100/1000Mbps

Description

ONV Industrial POE Switch 802.3 af/at 48V 4 8 16 24 PoE Port with 120W/240w power supply

The industrial PoE switches are independently developed by ONV. They can support IEEE 802.3af/at PoE standard, single-port PoE power up to 30W.  As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to PoE terminal device such as wireless AP, IP camera,industrial sensor through the network cable, and meet the network environment that needs high-density PoE power supply. It is suitable for intelligent transportation, rail transit, power industry, mining, petroleum, sea transportation. Industrial scenes such as metallurgy and green energy construction form a cost-effective, stable and reliable communication network.

Powerful port lightning protection, wide voltage input

Contact discharge 8KV, air discharge 15KV; port lightning protection common-mode 4KV, differential mode 2KV;



Industrial dual power input: DC INPUT: 48V-57V, non-PoE DC INPUT: 12-48V



Stable and reliable

Low power consumption, No fan, aluminum casing.

CCC,CE, FCC, RoHS.

The user-friendly panel, it can show the device status through the LED indicator of PWR,SYS, Link, L/A,PoE.








Model number: IPS33064P

Unmanaged Industrial PoE switch

4*10/100/1000M PoE port+ 2*10/100/1000M RJ45 uplink




Model number: IPS33064PF

Unmanaged Industrial PoE switch

4*10/100/1000M PoE port+ 2*10/100/1000M SFP uplink


Model number: IPS33064PFM

Managed Industrial PoE switch

4*10/100/1000M PoE port+ 2*10/100/1000M SFP uplink


Model number: IPS33108P

Unmanaged Industrial PoE switch

8*10/100/1000M PoE port+ 2*10/100/1000M RJ45 uplink


Model number: IPS33108PF

Unmanaged Industrial PoE switch

8*10/100/1000M PoE port+ 2*10/100/1000M SFP uplink




Model number: IPS33108PFM

Managed Industrial PoE switch

8*10/100/1000M PoE port+ 2*10/100/1000M SFP uplink



Product Details











ORDERING INFORMATION

Model

Description

IPS33064P

Unmanaged Industrial PoE switch with 4* 10/100/1000M PoE ports and 2* 10/100/1000M uplink RJ45 ports. Port 1-4 can support IEEE802.3af/at PoE Standard.

IPS33064PF

Unmanaged Industrial PoE switch with 4* 10/100/1000M PoE ports and 2* 10/100/1000M uplink SFP ports. Port 1-4 can support IEEE802.3af/at PoE Standard.

IPS33064PFM

Managed Industrial PoE switch with 4* 10/100/1000M PoE ports and 2* 10/100/1000M uplink SFP ports. Port 1-4 can support IEEE802.3af/at PoE Standard.

IPS33108P

Unmanaged Industrial PoE switch with 8* 10/100/1000M PoE ports and 2* 10/100/1000M uplink RJ45 ports. Port 1-8 can support IEEE802.3af/at PoE Standard.

IPS33108PF

Unmanaged Industrial PoE switch with 8* 10/100/1000M PoE ports and 2* 10/100/1000M uplink SFP ports. Port 1-8 can support IEEE802.3af/at PoE Standard.

IPS33108PFM

Managed Industrial PoE switch with 8* 10/100/1000M PoE ports and 2* 10/100/1000M uplink SFP ports. Port 1-8 can support IEEE802.3af/at PoE Standard.
Related products

IPS31064P

 Unmanaged Industrail PoE switch with 4*10/100M PoE ports and 2*10/100M uplink RJ45 ports. Port 1-4 can support IEEE802.3af/at PoE Standard.
IPS31128PFB Unmanaged Industrail PoE switch with 8*10/100M PoE ports, 2*10/100/1000M uplink SFP ports and 2*10/100M uplink RJ45 ports. Port 1-8 can support IEEE802.3af/at PoE Standard.
IPS31064PFM Managed Industrail PoE switch with 4*10/100M PoE ports, 2*10/100/1000M uplink SFP ports. Port 1-4 can support IEEE802.3af/at PoE Standard.
IPS31108PFM Managed Industrail PoE switch with 8*10/100M PoE ports, 2*10/100/1000M uplink SFP ports. Port 1-8 can support IEEE802.3af/at PoE Standard.
IPS31064 Unmanaged Industrail NON PoE switch with 4*10/100M RJ45 ports and 2*10/100M uplink RJ45 ports.
IPS31064FM Managed Industrail NON PoE switch with 4*10/100M RJ45 ports, 2*10/100/1000M uplink SFP ports.
IPS31108FM Managed Industrail NON PoE switch with 8*10/100M RJ45 ports, 2*10/100/1000M uplink SFP ports.
IPS33064 Unmanaged Industrail NON PoE switch with 4*10/100/1000M RJ45 ports and 2*10/100/1000M uplink RJ45 ports.

Dimensions:




Application:




Every product is unique, just like you. If you're looking for a product that fits the mold of your life, the ONV Industrial POE Switch 802.3 Af/at 48V 4/8/16/24 x 10/100/1000Mbps PoE Port with 120W/240w Power Supply, 16G switching capacity is for you.
