ONV Full Gigabit 14-port L2+ Managed industrial PoE switch, 10x 10/100/1000Base-T Ports + 4 (100/1000M) SFP ports, 28Gbps Switching

Regular price: R 16,084.50
Sale price: R 16,084.50
Regular price: ~~R 20,952.18~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

ONV Full Gigabit 14-port L2+ Managed industrial PoE switch, 10x 10/100/1000Base-T Ports + 4 (100/1000M) SFP ports, 28Gbps Switching, ONV-IPS33148PFM

SPECIFICATIONS

Brand: ONV

Certification: CE FCC RoHS

Dimensions (WxDxH): 165*148*54mm

MTBF: 539608 hours

Maximum power: 30W/port

Optical Transmission Distance: 550m-20km, or more, depends on optical module you used

PoE Port Output Voltage: PoE Port Output Voltage: DC48-57V

PoE Switch Interface: 10-Port 10/100/1000Base-T + 4 (100/1000M) SFP

Product Name: Industrial Gigabit 14-port PoE Switch

Warranty: 5 years, lifetime maintenance

Working Temperature: -40~80℃

Brand name: ONV

Communication mode: Full-Duplex & Half-Duplex

Function: LACP, POE, QoS, SNMP, VLAN Support

Model Number: ONV-IPS33148PFM

Ports: 14

Products status: Stock

Switch capacity: 28Gbps

Transmission Rate: 10/100/1000Mbps

Description

Managed 8PG+2G+4SFP 14-port Industrial PoE Switch

ONV-IPS33148PFM is a full gigabit managed industrial PoE+ switch independently developed by ONV. it has 8*10/100/1000M PoE ports and 2*10/100/1000M RJ45 ports and 4*100/1000M SFP fiber slot ports, port 1-8 can support IEEE 802.3af/at PoE standard, single port PoE power up to 30W, and the maximum PoE output power of the host is 120W.

Gigabit uplink 2.5Gbps line-speed switching

— Gigabit uplink SFP fiber port can support speed-up function, support up to 2.5Gbps line-speed switching, and can set professional high-speed ring network.

Powerful lightning protection, ultra-wide voltage input

— Contact discharge 8KV, air discharge 15KV; port lightning protection common-mode 4KV, differential mode 2KV;

— Industrial dual power input

— DC INPUT: 43V-55V, non-PoE DC INPUT: 12-55V.

Intelligent PoE power supply

— 8*10/100/1000Base-T RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

— IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

— Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

— PoE network management, realize PoE port power allocation, priority setting, port power status viewing, time scheduling, etc.

PoE network management and fast Ring function

— IEEE802.1Q VLAN, flexible VLAN division and QinQ configuration.

— QoS, Priority mode based on 802.1P, Port & DSCP, queue scheduling algorithm including EQU, SP, WRR & SP+WRR.

— ALC, filter data packet through configuring matching rules, processing operation & time permission, and provide flexible and safe access control.

— IGMP V1/V2 and IGMP Snooping.

— ERPS/STP/RSTP/MSTP.

— Static and dynamic aggregation.

Security

— 802.1X authentication.

— Port isolation,Storm control.

— IP-MAC-VLAN-Port binding.

Stable and reliable

— Low power consumption, fan-less design, aluminum shell.

— Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.

— CE, FCC, RoHS.

— The user-friendly panel, it can show the device status through the LED indicator of PWR,SYS, Link, PoE.

One-stop remote control and management

— Web management, CLI command line (Console, Telnet), SNMP (V1/V2/V3).

— HTTPS, SSLV3, and SSHV1/V2.

— RMON, system log, LLDP, and port traffic statistics.

— CPU monitoring, memory monitoring, Ping test, and cable diagnose.

Imagine if you could be satisfied and content with your purchase. That can very much be your reality with the ONV Full Gigabit 14-port L2+ Managed industrial PoE switch, 10x 10/100/1000Base-T Ports + 4 (100/1000M) SFP ports, 28Gbps Switching.
