MikroTik Routerboard 2011UIAS-2HND, multi-port device series designed for indoor use
Description
RB2011UiAS-2HnD-IN
2.4GHz AP, 5x Ethernet, 5x Gigabit Ethernet, SFP cage, USB, LCD, PoE output on Eth10, 600MHz CPU, 128MB RAM
The RB2011UiAS-2HnD-IN is a small form factor Ethernet router with 5 Gigabit Ethernet ports, 5 Fast Ethernet ports and an SFP cage.
The RB2011Ui is a low cost multi-port device series designed for indoor use. The RB2011 is powered by RouterOS, a fully featured routing operating system which has been continuously improved for fifteen years. Dynamic routing, hotspot, firewall, MPLS, VPN, advanced quality of service, load balancing and bonding, real-time configuration and monitoring - just a few of the vast number of features supported by RouterOS.
The RouterBOARD 2011UiAS-2HnD has most features and interfaces from all the MikroTIK Wireless routers. It’s powered by the new Atheros 600MHz 74K MIPS network processor, has 128MB RAM, five Gigabit LAN ports, five Fast Ethernet LAN ports and SFP cage (SFP module not included!). It also features powerful 1000mW dual-chain 2.4Ghz (2312-2732MHz depending on country regulations) 802.11bgn wireless AP, RJ45 serial port, microUSB port and RouterOS L5 license, as well as a desktop case with power supply, two 4dBi Omni antennas and LCD panel. Tested and recommended to use with MikroTik SFP modules: S-85DLC05D, S-31DLC20D and S-35/53LC20D (not included).
The RouterBOARD 2011UAS-2HnD-IN comes with a desktop enclosure, LCD panel and power supply. The RB2011Ui also has passive PoE output capability on the last port (ETH10), this means you can power another device just by connecting it over a regular Ethernet cable.
Features:
- Desktop metal case with touchscreen LCD
- 5 x 10/100 Ethernet ports & 5 x 10/100/1000 Ethernet ports
- 1 x SFP Cage (SFP not included)
- 2.4GHz dual chain 802.11b/g/n Wireless (2 x 2.5dBi swivel antennas included)
- 600MHz CPU, 128MB RAM
- USB Port (microUSB)
- PoE in & PoE out (on port 5)
- RouterOS L5
Specifications
Details |
Product code |
RB2011UiAS-2HnD-IN |
Architecture |
MIPSBE |
CPU |
AR9344 |
CPU core count |
1 |
CPU nominal frequency |
600 MHz |
Switch chip model |
AR8327 |
Dimensions |
214mm x 86mm for PCB |
RouterOS license |
5 |
Operating System |
RouterOS |
Size of RAM |
128 MB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 60°C |
Suggested price |
N/A |
Wireless capabilities
Details |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz standards |
802.11b/g/n |
Antenna gain dBi for 2.4 GHz |
4 |
Wireless 2.4 GHz chip model |
AR9344 |
Wireless 2.4 GHz generation |
Wi-Fi 4 |
Ethernet
Details |
10/100 Ethernet ports |
5 |
10/100/1000 Ethernet ports |
5 |
Fiber
Details |
SFP DDMI |
Yes |
SFP ports |
1 |
Peripherals
Details |
Serial console port |
RJ45 |
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Powering
Details |
Number of DC inputs |
2 (PoE-IN, DC jack) |
DC jack input Voltage |
8-30 V |
Max power consumption |
11 W |
Cooling type |
Passive |
PoE in |
Passive PoE |
PoE in input Voltage |
8-30 V |
PoE-out
Details |
PoE-out ports |
Ether10 |
PoE out |
Passive PoE |
Max out per port output (input 18-30 V) |
510 mA |
Max total out (A) |
510 mA |
Certification & Approvals
Details |
Certification |
CE, FCC, IC, EAC, ROHS |
IP |
IP20 |
Other
Details |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Beeper |
Yes |
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
1MBit/s |
30 |
-96 |
11MBit/s |
28 |
-80 |
6MBit/s |
30 |
-96 |
54MBit/s |
27 |
-80 |
MCS0 |
30 |
-92 |
MCS7 |
25 |
-73 |
Included parts
The MikroTik Routerboard 2011UIAS-2HnD-IN, 5x10/100 Ethernet ports, 5×10/100/1000 Ethernet ports, 1×SFP cage (SFP not incl), 2.4GHz dual-chain 802.11b/g/n destined to impress, and priced at only R 4,059.93, for a limited time.
