MikroTik CRS310-1G-5S-4S+IN L3 management 10-port cloud Router switch 10G, 1× 1G SFP port, 4× 10G SFP+ ports, 1GbE port, RouterOS
Description
This switch is an indoor variation of the prominent netFiber 9 switch – used by many small and medium ISPs for reliable 10 Gigabit fibre connections stretching over a 100 meters. With five 1G SFP ports, four 10G SFP+ ports, and an additional Gigabit Ethernet port, this is the perfect upgrade for existing CRS212 setups. You’re getting the modern ARM v7 CPU, 256 MB of RAM, and better cooling. The new Marvell switch-chips bring phenomenal performance to the table!
The Gigabit Ethernet port has a direct connection to the switch chip – so you can enjoy full gigabit speed there. And it supports PoE-in, giving you an additional powering option in tricky spots.
You can mount this switch in a standard 1U rack to keep everything organized. And it has all the power you would expect from a rackmount device: CRS310 supports hardware offloaded VLAN- filtering. And even some hardware offloaded Layer-3 routing.
CRS310-1G-5S-4S+IN is a fantastic tool for anyone working with indoor connections over 100 meters while keeping data loss and ping low. Optical fiber can be a great alternative to copper if you are worried about electromagnetic interference, tampering or eavesdropping.
Technical Specifications
MikroTik CRS310-1G-5S-4S+IN three-layer network management 10-port cloud routing switch 10G
Details |
|
Certification |
CE, CCC, FCC |
IP |
20 |
Certification & Approvals
Details |
|
CPU temperature monitor |
Yes |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Other
Details |
|
Serial console port |
RJ45 |
Peripherals
Details |
|
SFP ports |
5 |
SFP+ ports |
4 |
Fiber
Details |
|
10/100/1000 Ethernet ports |
1 |
Ethernet
Details |
|
Number of DC inputs |
2 (PoE-IN, DC jack) |
DC jack input Voltage |
18-57 V |
Max power consumption |
20 W |
Max power consumption without attachments |
8 W |
Cooling type |
1 |
PoE in |
802.3af/at |
PoE in input Voltage |
18-57 V |
Powering
Product code |
CRS310-1G-5S-4S+IN |
Architecture |
ARM 32bit |
CPU |
98DX226S |
CPU core count |
1 |
CPU nominal frequency |
800 MHz |
Dimensions |
200 x 166 x 45 mm |
RouterOS license |
5 |
Operating System |
RouterOS |
Size of RAM |
256 MB |
Storage size |
16 MB |
Storage type |
FLASH |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
SPECIFICATIONS
Brand Name: MikroTik
High-concerned Chemical: None
Fiber Type: Single Mode
Connector Type: Hybrid
Model Number: CRS310-1G-5S-4S+IN
Certification: CE
Certification: FCC
Certification: RoHS
Model Number: Router
Firmware: English version
Transmission Rate:: 10/100/1000Mbps
Switch Capacity:: 10Gbps
LAN Ports:: 10port
