MikroTik CRS112-8P-4S-IN 8*Gigabit Ethernet Smart Switch with PoE-out, 4*SFP cages, 400MHz CPU, 128MB RAM, desktop case, RouterOS L5

MikroTik CRS112-8P-4S-IN Cloud Router Switch 8*Gigabit Ethernet Smart Switch with PoE-out, 4*SFP cages, 400MHz CPU, 128MB RAM, desktop case, RouterOS L5

SPECIFICATIONS

Brand Name: MikroTik

High-concerned Chemical: None

DIY Supplies: ELECTRICAL

Products Status: Stock

Ports: 12

Transmission Rate: 10/100/1000Mbps

Function: LACP, POE, QoS, SNMP, VLAN Support

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 24Gbps

Brand Name: MikroTik

Model Number: CRS112-8P-4S-IN, CRS112-8P-4S-IN

CPU: QCA8511

10/100/1000 Ethernet ports: 8

SFP ports: 4

Power consumption: Max 160 W

Storage size: 16 MB

CPU nominal frequency: 400 MHz

Size of RAM: 128 MB

Storage type: FLASH

Warranty: 1 Year

MikroTik CRS112-8P-4S-IN 4 SFP Gigabit ROS wired PoE routing desktop Router Switch

Descriptions

MikroTik CRS112-8P-4S-IN 8*Gigabit Ethernet Smart Switch with PoE-out, 4*SFP cages, 400MHz CPU, 128MB RAM, desktop case, RouterOS L5

CRS112-8P-4S-IN is an eight Gigabit RJ45 port PoE switch, that offers different power output options: autosensing 802.3af/at PoE/PoE+ and Passive PoE, and four SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.

CRS112-8P-4S-IN is equipped with 12 independent switching ports. 28 V 3.4 A power supply is already included in the box. There is secondary DC jack on the back of the enclosure that supports 48-57 V power supply (not included, can be purchased separately - product codes 48POW (1.46A 70W) and 48V2A96W (2A 96W)). CRS112-8P-4S-IN can power 802.3af/at devices if 48-57 V DC input is used (unit will automatically detect and provide correct power to devices). Max current is 1 A per port if input voltage is 18-28 V, 450 mA if 48-57 V. Total limit is 2.8A@24V and 1.4A@48-57V. PoE-Out is passed over mode B 4,5 (+) and 7,8 (-) pins

Specifications

Powering

Ethernet
