Mikrotik Cloud Router Switch CRS326-24G-2S+RM with 2x 40G QSFP+ cages, 24 10G SFP+ cages, 1x LAN port for management, RouterOS L5/SwitchOS dual boot

Description

CRS326-24G-2S+RM

Mikrotik Cloud Router Switch 326-24S+2Q+RM with 2 x 40G QSFP+ cages, 24 10G SFP+ cages, 1x LAN port for management, RouterOS L5 or SwitchOS (dual boot), 1U rackmount enclosure, Dual redundant PSU

CRS326-24G-2S+RM - 24 Gigabit port switch with 2 x SFP+ cages in 1U rackmount case, Dual boot (RouterOS or SwitchOS)

SwOS/RouterOS powered 24 port Gigabit Ethernet switch with two SFP+ ports, wire speed connectivity with several new switching features!

It has “Dual boot” feature that allows you to choose which operating system you prefer to use, RouterOS or SwOS. If you prefer to have a simplified switch only OS with more switch specific features, use SwOS. If you are used to Winbox and would like the ability to use routing and other Layer 3 features on some ports in your CRS, boot and use RouterOS. You can select the desired operating system from RouterOS, from SwOS or from the RouterBOOT loader settings.

It gives you all the basic functionality for a managed switch, plus more: allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields. SFP cage supports both 1.25 Gb SFP and 10 Gb SFP+ modules.

Specifications

Details
Product code CRS326-24G-2S+RM
Architecture ARM 32bit
CPU 98DX3236
CPU core count 2
CPU nominal frequency 800 MHz
Switch chip model 98DX3236
Dimensions 443 x 144 x 44 mm
RouterOS license 5
Operating System RouterOS / SwitchOS
Size of RAM 512 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 60°C
Suggested price N/A

Powering

Details
Number of DC inputs 2 (PoE-IN, DC jack)
DC jack input Voltage 10-30 V
Max power consumption 24 W
PoE in Passive PoE
Cooling type Passive
PoE in input Voltage 10-30 V

Ethernet

Details
10/100/1000 Ethernet ports 24

Fiber

Details
SFP+ ports 2

Peripherals

Details
Serial console port RJ45

Certification & Approvals

Details
Certification CE, EAC, ROHS
IP IP20

Included parts

Every product is unique, just like you. If you're looking for a product that fits the mold of your life, the Mikrotik Cloud Router Switch CRS326-24G-2S+RM with 2x 40G QSFP+ cages, 24 10G SFP+ cages, 1x LAN port for management, RouterOS L5/SwitchOS dual boot is for you.
