MikroTik CCR1016-12S-1S+ Cloud Router Switch 1U Rackmount, 12xSFP cage, 1xSFP+, 16 cores x 1.2GHz CPU, 2GB RAM, LCD panel, Dual Power, RouterOS L6

Description

CCR1016 is an industrial grade router with a cutting edge 16 core Tilera CPU. If you need many millions of packets per second - Cloud Core Router is your best choice.

This model has twelve SFP ports and one SFP+ port for 10G connectivity. It is available in a 1U rackmount case and also has a serial console port, a touchscreen LCD and a USB port.

The CCR1016-12S-1S+ comes with redundant power supplies and one RJ45 SFP 10/100/1000M copper module.

Specifications

  • Product code: CCR1016-12S-1S+
  • Suggested price: $815.00
  • Architecture: TILE
  • CPU: TLR4-01680
  • CPU core count: 16
  • CPU nominal frequency: 1.2 GHz
  • CPU Threads count: 16
  • Dimensions: 443 x 197 x 44 mm
  • RouterOS license: 6
  • Operating System: RouterOS
  • Size of RAM: 2 GB
  • Storage size: 128 MB
  • Storage type: NAND
  • MTBF: Approximately 200'000 hours at 25C
  • Tested ambient temperature: -20°C to 60°C

Powering

  • Number of AC inputs: 2
  • AC input range: 100-240
  • Max power consumption: 47.5 W
  • Max power consumption without attachments: 34 W
  • Cooling type: 2 fans

Fiber

  • SFP DDMI: Yes
  • SFP ports: 12
  • SFP+ ports: 1

Peripherals

  • Memory card type: microSD
  • Memory Cards: 1
  • Serial console port: RJ45
  • Number of USB ports: 1
  • USB Power Reset: Yes
  • USB slot type: USB type A
  • Max USB current (A): 1

Other

  • CPU temperature monitor: Yes
  • PCB temperature monitor: Yes
  • Mode button: Yes
  • Beeper: Yes

Certification & Approvals

  • Certification: CE, EAC, ROHS
  • IP: IP20

Product Details

CCR1016 is an industrial grade router with a cutting edge 16 core Tilera CPU. If you need many millions of packets per second - Cloud Core Router is your best choice.

This model has twelve SFP ports and one SFP+ port for 10G connectivity. It is available in a 1U rackmount case and also has a serial console port, a touchscreen LCD and a USB port.

The CCR1016-12S-1S+ comes with redundant power supplies and one RJ45 SFP 10/100/1000M copper module

Details
Product code CCR1016-12S-1S+
Architecture TILE
CPU TLR4-01680
CPU core count 16
CPU nominal frequency 1.2 GHz
Dimensions 443 x 197 x 44 mm
RouterOS license 6
Operating System RouterOS
Size of RAM 2 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 60°C
IPsec hardware acceleration Yes



Powering

Details
Number of AC inputs 2
AC input range 100-240
Max power consumption 47.5 W
Max power consumption without attachments 34 W
Cooling type 2 fans



Fiber

Details
SFP DDMI Yes
SFP ports 12
SFP+ ports 1



Peripherals

Details
Memory card type microSD
Memory Cards 1
Serial console port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1

The MikroTik CCR1016-12S-1S+ Cloud Router 1U, 12xSFP cage, 1xSFP+, 16 cores x 1.2GHz CPU, 2GB RAM, LCD panel, Dual Power, RouterOS L6 is the product you didn't think you need, but once you have it, something you won't want to live without.
