MERCURY 18Port 16PoE 214W 1000Mbps VLAN Switch IEEE802.3af/at Max PoE 214W 18 ports Ethernet PoE RJ45 Gigabit Switch Plug&Play

MERCURY 18Port 16PoE 214W 1000Mbps VLAN Switch IEEE802.3af/at Max PoE 214W 18 ports Ethernet PoE RJ45 Gigabit Switch Plug&Play

SPECIFICATIONS

Brand Name: MERCURY

Function: VLAN Support

Function: QoS

Function: POE

Number of Interfaces: 18

Switch Type: Gigabit Switch

Package: No

Communication Mode: Full-Duplex

Model Number: 1000Mbps 18 ports 16 PoE 214W

Transmission Rate: 10/100/1000Mbps

VLAN: Supports VLAN

Dimensions (L * W * H): 294mm * 180mm * 44mm

AC Input Voltage: 100V - 240V

Package Content: Switch *1pcs

Support PoE port: 16 Ports

Cabinet: Metal / Steel

Standards: IEEE 802.3af/at, IEEE802.3ab, IEEE802.3u, IEEE802.3x

Maximum power of the whole machine: is 214W

Maximum power of a single port: is 30W

Mode Shifter: Standard / Video Monitor / VLAN

Key Features:

(1).Provides 18* 10/100M/1000M adaptive RJ45 ports, 1 - 16 ports support PoE output.

(2).Each port supports MDI/MDIX auto-flip and auto-negotiation.

(3).Supports IEEE 802.3X full-duplex flow control and Backpressure half-duplex flow control.

(4).Supports IEEE 802.3af/at standard, automatically detect and identify and power the IEEE 802.3af/at compliant powered device (PD).

(6).Power output power up to 214W, single port PoE power up to 30W.

(7).Plug and play, no configuration, simple and convenient.

(8).Rackable design, Dimension (L * W * H): 294mm x 180mm x 44mm.

(9).Three working modes

Under the standard switching mode, all of the ports are free of communication, which is suitable for the common data transmission environment;

Video monitoring mode, designed for monitoring applications, which can effectively reduce Caton and mosaic phenomenon in monitoring network;

VLAN isolation mode, 16 ports are isolated from each other, suitable for connection of wireless AP, can effectively inhibit the network storm, enhance the performance of the wireless network.
