KeepLiNK Industrial 5-Port 10/100 Mbps Ethernet Switch Rugged Metal Housing IP40 DIN-Rail Mountable KP-9000-45-5TXm

R 2,637.66
R 2,637.66
R 3,165.19
Sold out
Shipping calculated at checkout.

KeepLiNK Industrial 5-Port 10/100 Mbps Ethernet Switch | Rugged Metal Housing IP40 | DIN-Rail Mount | Wide Temperature Range

SPECIFICATIONS

Brand Name: keepLiNK

Buffer: 768 K

Certification: CE,FCC,RoHS

Choice: yes

Communication Mode: Full-Duplex & Half-Duplex

Dimensions: 95 x 91 x 31 mm (3.74 x 3.58 x 1.22 in)

Enclosure: Metal

Forwarding Delay: 5us

Function: VLAN Support

High-concerned chemical: None

IP Level: IP40

Input Voltage: 12 to 58VDC

MAC Address Table Size: 2 K

Model Number: KP-9000-45-5TXm

Operating Temperature: -40℃~+75℃

Package: Yes

Packet Forwarding Rate: 0.744 Mpps

Power: 5W

Storage Temperature: -40℃~+75℃

Switch Capacity: 1G

Switch Type: Fast Switch

Transmission Rate: 10/100Mbps

VLAN: Yes

Weight: 0.3 kg

Description

Upgrade your industrial network with this 5-Port Megabit Ethernet Switch, designed for harsh environments. Built with a heavy-duty metal housing, this switch ensures reliable 10/100 Mbps Fast Ethernet connectivity for industrial automation, surveillance, and control systems. Featuring DIN-rail mounting, wide operating temperature range (-40°C to 75°C), and high EMI protection, it’s perfect for factories, power plants, and outdoor installations.

  • Plug-and-play setup with no configuration needed

  • Non-blocking switching for seamless data transfer

  • Redundant power input (12-48V DC) for fail-safe operation

  • IP40 protection against dust and moisture

  • 5-year warranty for peace of mind

Ideal for SCADA systems, IoT networks, and industrial automation where durability and stability are critical.



Key Features:

  • 5 x 10/100 Mbps RJ45 ports (Auto-MDI/MDIX, auto-negotiation)

  • Industrial-grade metal casing (IP40 protection)

  • DIN-rail mounting

  • Wide operating temperature: -40°C to 75°C

  • Dual power inputs (12-48V DC) with reverse polarity protection

  • Low power consumption & fanless design (silent operation)

  • Store-and-forward switching with 1Gbps backplane bandwidth

  • EMI/ESD protection for stable performance in noisy environments

  • Plug-and-play, no software configuration required



Applications:

  • Factory automation & machinery

  • Oil & gas, mining, and transportation systems

  • Smart city & traffic control networks

  • Renewable energy (solar/wind farm monitoring)

  • Security cameras & NVR systems

The KeepLiNK Industrial 5-Port 10/100 Mbps Ethernet Switch Rugged Metal Housing IP40 DIN-Rail Mountable KP-9000-45-5TXm is a sensational customer favorite, and we hope you like it just as much.
