KeepLiNK 54-Port Managed PoE Switch 48× Gigabit PoE+ (700W) + 6 × 10G SFP+ Layer 3 Rack-Mounted Enterprise Network Switch
SPECIFICATIONS
Brand Name: keepLiNK
Buffer: 16 M
Certification: CE,FCC,RoHS
Communication Mode: Full-Duplex & Half-Duplex
Dimensions: 440 x 284 x 44 mm
Ethernet Port: 48-PoE Gigabit
Forwarding delay: <10 us
Function: POE,QoS,SNMP,VLAN Support
High-concerned chemical: None
Input Voltage: AC 100-240V 50/60Hz
MAC address table: 32 K
Model Number: KP-9000-54XGPM-X6-ACR
Mounting: Rack-Mounted
Package: Yes
Packet forwarding rate: 160.7Mpps
PoE Port: 1-48
PoE Power Budget: 700W
PoE Protocol: IEEE802.3af/at
SFP Port: 6 x 10G SFP+
Switch Capacity: 216G
Transmission Rate: 10000 Mbps
VLAN: Yes,3k
Weight: 4.2 kg
Description
High-Performance 54-Port Managed PoE Switch for Enterprise Networks
Upgrade your network with the KeepLiNK 54-Port Layer 3 Managed Switch, designed for high-density deployments requiring power, speed, and advanced control. Ideal for offices, data centers, and IP surveillance systems.
Key Features:
● 48× Gigabit PoE+ Ports – Deliver up to 30W per port (IEEE 802.3af/at) with a total 700W PoE budget for powering IP cameras, VoIP phones, and wireless APs.
● 6× 10G SFP+ Uplinks – High-speed fiber/copper uplinks for backbone connectivity, reducing bottlenecks.
● Layer 3 Managed – Advanced routing (static/RIP/OSPF), VLAN, QoS, ACL, and IPv6 support for secure, segmented networks.
● Robust Cooling & Rack-Mountable – Silent fan design with metal housing; fits standard 19" racks (1U height).
● Easy Management – Web GUI, CLI, and SNMP for remote monitoring and configuration.
