keepLink 19-Port Ethernet Switch with 19-PoE 10/100M and 2-100/1000M Gigabit and 1-SFP for Uplink Unmanaged Switch

keepLink 19-Port Ethernet Switch with 19-PoE 10/100M and 2-100/1000M Gigabit and 1-SFP for Uplink Unmanaged Switch

SPECIFICATIONS

Brand Name: keepLiNK

Hign-concerned Chemical: None

Function: POE

Function: VLAN Support

Number of Interfaces: 20

Certification: CE

Certification: FCC

Certification: RoHS

Switch Type: Gigabit Switch

Package: Yes

Communication Mode: Full-Duplex & Half-Duplex

Model Number: KP-9000-19GTP-SG2

Transmission Rate: 10/100/1000Mbps

VLAN: Yes

Switch Capacity: 9.2G

PoE Ports: 16

100/1000M RJ45 Port: 2

100/1000M SFP Port: 1

Enclosure: Metal

Connector Type: Metal

Form-Factor: Desktop/Wall mount

Max MAC entries: 2K

Buffer Size: 768k bit

Jumbo frame support: 2k bytes

Acoustic noise level @ 25° C (dBA) (ANSI-S10.12): 0

Auto MDI/MDI-X Cable Detection: Yes

Auto-sensing Half/Full Duplex Switched Ports: Yes

Short Cable Detection/Power Saving: Yes

Operating Temperature: 32° to 104°F (0° to 40°C)

Humidity (relative): 90% maximum relative humidity (RH), non-condensing

Altitude: 10,000 ft (3,000 m) maximum

Storage Temperature: -4° to 158°F (-20° to 70°C)

Humidity (relative): 95% maximum relative humidity (RH), non-condensing

Altitude: 10,000 ft (3,000 m) maximum

Electromagnetic Certifications and Compliance: CE, FCC part 15 Class B

Safety Certifications: CE LVD

Hardware warranty: 1-year warranty

Package Contents: KeepLink Unmanaged Switch Power Adapter User Manual

PoE Power Budget: 300W

PoE Protocol: IEEE802.3af/at

PoE Max. Power: 30W

Product size: 319 x 208 x 45 mm

Weight: 1.7 kg

Product Description

keepLink 19-Port Ethernet Switch with 19-PoE 10/100M and 2-100/1000M Gigabit and 1-SFP for Uplink Unmanaged Switch
