Juniper QFX5110-48S-AFI2 48-port network switch 48SFP+ & 4QSFP28, back to front air flow, AC QFX5110 access and aggregation switch

Regular price: R 93,678.95
Sale price: R 93,678.95
Regular price: ~~R 95,515.95~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

Juniper QFX5110-48S-AFI2 48-port network switch 48*SFP+ and 4*QSFP28, back to front air flow, AC QFX5110 access and aggregation switch

Description

48 SFP+ and 4 QSFP28, back to front air flow, AC

QFX5110 access and aggregation switches deliver low latency, rich Layer 2 and Layer 3 features, VXLAN overlay deployments, and 100GbE uplinks, making it the industrys most nimble line of switches.

Featuring L3 gateway capabilities for bridging between virtualized and bare-metal servers, the QFX5110 is designed for extremely agile data centers that demand support for overlay/underlay network architectures. The high-density 10GbE, 40GbE, and 100GbE ports also make the QFX5110 ideally suited for use in data center spine and leaf topologies and campus distribution.

QFX5110 highlights:
Support high-density, multi-speed configurations for 10/40/100GbE access and aggregation, with up to 64 or 96 10GbE ports, up to four 100GbE uplink ports, and up to 32 40GbE ports in a 1 U platform

Deliver up to 2.56 Tbps Layer 2 and Layer 3 performance, with latency as low as 550 nanoseconds

Include a 1.8 GHz quad-core Intel CPU with 16 GB memory and 64 GB SSD storage

Feature rich automation capabilities with support for Python and zero touch provisioning (ZTP)
Support virtualization protocols such as Virtual Extensible LAN (VXLAN) and Open vSwitch Database (OVSDB) protocol as L2 Gateway or L3 Gateway

Offer advanced Junos OS features such as BGP add-path, MPLS, L3 VPN, and IPv6 6PE

Specs

Product Code	QFX5110-48S-AFI2
Dimensions(WxHxD)	1.72 x17.36 x 20.48 in(4.37 x 44.09 x 52.02 cm)
Rack units	1 U
Weight	23 lb (10.43 kg)
Operating system	Junos OS
CPU	1.8 GHz quad-core Intel CPU
Power	AFO/AFI: Max load: 300 W, Typical load: 195 W, Idle load: 150 W Dual redundant (1+1) and hot-pluggable power supplies 110-240 V single phase AC power -36 to -72 V DC power
Cooling	Redundant (N+1) and hot-pluggable fan modules for front-to-back and back-to-front airflow Redundant variable-speed fans to reduce power draw
Total packet buffer	16 MB
Warranty	Juniper standard one-year warranty
System Throughput	Up to 1.76 Tbps (bidirectional)
Forwarding Capacity	1.32 Bpps

Product Details

Specifications

QFX5110-48S-AFI2 Specification
Dimensions (W x H x D)	1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm)
Rack units	1 U
Weight	23 lb (10.43 kg)
Operating system	Junos OS
CPU	1.8 GHz quad-core Intel CPU
Power	AFO/AFI: Max load: 300 W, Typical load: 195 W, Idle load: 150 W Dual redundant (1+1) and hot-pluggable power supplies 110-240 V single phase AC power -36 to -72 V DC power
Cooling	Redundant (N+1) and hot-pluggable fan modules for front-to- back and back-to-front airflow Redundant variable-speed fans to reduce power draw
Total packet buffer	16 MB
Warranty	Juniper standard one-year warranty
System Throughput	Up to 1.76 Tbps (bidirectional)
Forwarding Capacity	1.32 Bpps
Interface Options	1GbE SFP: 48 (24 copper 1GbE) 10GbE SFP+: 48/64 (with breakout cable) 40GbE QSFP+: 4 100GbE QSFP28: 4
Other Interface Notes	Each QSFP+ port can be configured as a 4 x 10GbE interface or as a 40 Gbps port Each QSFP28 port can be configured as a 4 x 10GbE interface a 40 Gbps port or as a 100 Gbps port 1 USB 2.0 port 1 RS-232 console port 2 management ports: 2x SFP fiber ports or 1x RJ-45 and 1x copper SFP ports Supported transceiver and direct attach cable SFP+ 10GbE optical modules SFP+ DAC cables: 1/3/5 m twinax copper and 1/3/5/7/10 m active twinax copper SFP GbE optical and copper module QSFP+ DAC cables: 1/3/5 m twinax copper and 7/10 m active twinax copper QSFP+ AOC cables: 1/3/5/7/10/15/20/30 m cable QSFP+ Optics: SR4, LX4, ESR4, IR, LR4 QSFP+ to SFP+ 10GbE direct attach breakout copper (1/3/10 m twinax copper and 5/7 m active twinax copper cable) QSFP28 Optics: SR4, CWDM4, LR4 QSFP28 AOC: 10 m cable
MAC addresses per system	288,000
VLAN IDs	4,093
Number of link aggregation groups (LAGs)	104
Number of ports per LAG	32
Firewall filters (ingress / egress)	6,142 / 1,022
IPv4 unicast routes	128,000 prefixes; 208,000 host routes; 64 ECMP paths
IPv4 multicast routes	104,000
IPv6 unicast routes	84,000
IPv6 multicast routes	52,000
ARP entries	48,000
Jumbo frame	9,216 bytes
Spanning Tree Protocol (STP)	Multiple Spanning Tree Protocol (MSTP) Instances: 64 VLAN Spanning Tree Protocol (VSTP) Instances: 253
Traffic mirroring	Mirroring destination ports per switch: 4 Maximum number of mirroring sessions: 4 Mirroring destination VLANs per switch: 4
Operating temperature	32° to 104° F (0° to 40° C)
Storage temperature	-40° to 158° F (-40° to 70° C)
Operating altitude	Up to 2,000 ft (610 m)
Relative humidity operating	Operating: 5% to 90% (noncondensing)
Relative humidity non-operating	Non-operating: 0% to 95% (noncondensing)

Imagine if you could be satisfied and content with your purchase. That can very much be your reality with the Juniper QFX5110-48S-AFI2 48-port network switch 48*SFP+ & 4*QSFP28, back to front air flow, AC QFX5110 access and aggregation switch.
