Huawei S5720S-28X-SI-DC 24 Ethernet 10/100/1000 ports,4 10 Gig SFP+,DC -48V 24Port Enterprise Ethernet Switch, 336 Gbit/s Switching

Huawei S5720S-28X-SI-DC 24 Ethernet 10/100/1000 ports,4 10 Gig SFP+,DC -48V 24Port Enterprise Ethernet Switch, 336 Gbit/s Switching

SPECIFICATIONS

Brand Name: HUAWEI

Installation Method: Assembly

High-concerned Chemical: None

Private Mold: NO

Products Status: Stock

Ports: 24

Transmission Rate: 96 Mpps

Function: LACP, Stackable

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 336 Gbit/s

Model Number: S5720S-28X-SI-DC

Place of Origin: Beijing, China

Model: S5720S-28X-SI-DC

Memory (RAM): 512 MB

Rated voltage range: -48 V DC to -60 V DC

Dimensions (H x W x D): 43.6 mm x 442.0 mm x 224.9 mm (1.72 in. x 17.4 in. x 8.85 in.)

PoE: Not supported

Maximum power consumption: 33 W

Storage temperature: -40°C to +70°C (-40°F to +158°F)

Software Version: V200R009C00 to V200R019C10 versions

Warranty: 12 Month

Condition: 100% Original Brand

Description

Huawei S5720S-28X-SI-DC 24 Ethernet 10/100/1000 ports,4 10 Gig SFP+,DC -48V 24Port Enterprise Ethernet Switch, 336 Gbit/s Switching

Technical Specifications

48-port Full Gigabit POE Enhanced Ethernet Switch 5720-56C-PWR-EI-AC1

Flexible Gigabit Ethernet switches that provide resilient, high-density Layer 3 switching for data centers. Features include multiple-terminals, HD video surveillance, and video conferencing applications. Intelligent iStack clustering, 10 Gbit/s upstream ports and IPv6 forwarding enable use as aggregation switches in enterprise campus networks.Next-generation reliability, security, and energy-saving technologies make S5720-SI Series Switches easy to install and maintain, and an excellent source of low Total Cost of Ownership (TCO).

Product Highlights

Services

Layer 3 features such as OSPF, IS-IS, BGP, and VRRP provide services such as voice, video, and data.

iStack Properties

Intelligent Stack (iStack) virtualizes multiple switches into one, improving device reliability, simplifying configuration and
management, and providing configuration-free stacking.

SVF for Ultra-Simplified Network O&M
Huawei's Super Virtual Fabric (SVF) virtualizes the campus network architecture of Core / Aggregation Switches + Access Switches +
APs' into a single network element for simplified network O&M. The S5720-SI also can work as an SVF plug-and-play client.
