Huawei Multi-Service Control Gateways ME0P08BASA70 Basic Configuration Incl. ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C, 4*AC

R 641,051.95
R 641,051.95
R 754,178.95
Sold out
Shipping calculated at checkout.

Huawei Multi-Service Control Gateways ME0P08BASA70 Basic Configuration Incl. ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C, 4*AC Power

SPECIFICATIONS

Brand Name: HUAWEI

High-concerned Chemical: None

DIY Supplies: ELECTRICAL

Certification: CE

Model Number: ME0P08BASA70

Type: Enterprise Router

Brand Name: HUAWEI

Use: Industries

Network: Wireless LAN

Architecture Multi Bus Mmulti: CPU

Transport Package: Paper Box Each Set

Specification: Brand new sealed

Production Capacity: 200set/Month

Switching Capacity: 12.58 Tbit/s

Dimensions (W x D x H): 442 mm x 650 mm x 620 mm (14U)

Maximum Power Consumption: 2,340W (120G) 4,100W (240G)

Full Configuration Weight: 119 kg (120G) 136 kg (240G)

L2TP Session number: up to 64K/per slot, up to 128K/per chassis

Multicast: IPoE access users

Product Description

The ME60 is a multi-service control gateway series launched by HW. ME60s are mainly used as broadband service access BRAS nodes and IP/MPLS network service-provisioning nodes.

The ME60 uses HW-developed Solar series NP chips. In addition, the ME60 uses the CLOS distributed multilevel switching architecture, and leverages distributed hardware-based forwarding and non-blocking switching to achieve excellent line-speed forwarding performance, superb scalability, comprehensive QoS, and strong service processing capabilities. Based on an industry-leading 2 Tbit/s platform, the ME60 is compatible with the line cards already installed on existing networks, which helps to maximize the protection of customer investment.

The ME60 is a high-performance service management and provisioning platform, which fully meets the requirements of a variety of service-provisioning modes, carries multiple services simultaneously, and ensures that a wide range of telecommunication services
run stably and reliably. By using the ME60 and corresponding solutions, operators can construct a future-oriented intelligent broadband IP network with greatly reduced multi-service network construction and O&M costs.

The ME60 series includes the following models, which can meet the requirements of networks of various scales: ME60-X16A, ME60-X8A,ME60-X16, ME60-X8, and ME60-X3.

Specification

item

value

Model Number

ME0P08BASA70

Type

Enterprise Router

Place of Origin

N/A





Brand Name

Huawei

Use

Industries

Network

Wireless Lan

Architecture Multi Bus Mmulti

CPU

Transport Package

Paper Box Each Set

Specification

Brand new sealed

Production Capacity

200set/Month

Switching Capacity

12.58 Tbit/s

Dimensions (W x D x H)

442 mm x 650 mm x 620 mm (14U)

Maximum Power Consumption

2,340W (120G) 4,100W (240G)

Full Configuration Weight

119 kg (120G) 136 kg (240G)

L2TP Session number

up to 64K/per slot, up to 128K/per chassis

Multicast replication

IPoE access users

Huawei ME60 Series Multi-Service Control Gateways

HW ME60-X8 Series Gateways ME0P08BASA70 HW Router
* ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C,

4 AC Power, without Software Charge and Document)

No

Part Number

Model

Description

1



ME0P08BASD75

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),4 DC Power,2 Fan Tray, without Software Charge and
Document)

2



ME0P08BASA75

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),6 AC Power,2 Fan Tray,without Software Charge and
Document)

3



ME0P08BASD77

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),6 HVDC Power,2 Fan Tray, without Software Charge and
Document)

4



ME0P08BASD7D

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),4 DC Power,2 Fan Tray, without Software Charge and
Document)

5



ME0P08BASA7D

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),6 AC Power,2 Fan Tray,without Software Charge and
Document)

6



ME0P08BASH71

ME60-X8A Basic Configuration (Including ME60-X8A Chassis,2 SRUs,2 SFUs(480G),6 HVDC Power,2 Fan Tray, without Software Charge and
Document)

7



ME0P08BASA7M

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 Redundant 200G SRU/SFU, 4 AC Power(Power Cords Cable), without
Software Charge and Document)

8



ME0P08BASA70

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C, 4 AC Power, without Software Charge and
Document)

9



ME0P08BASD70

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C, 4 DC Power, without Software Charge and
Document)

10



ME0P08BASD73

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 Redundant 200G SRU/SFU, 4 DC Power, without Software Charge and
Document)

11



ME0P08BASA73

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 Redundant 200G SRU/SFU, 4 AC Power, without Software Charge and
Document)

12



ME0P08BASA74

ME60-X8 Basic Configuration (Including ME60-X8 Chassis, 2+1 Redundant 200G SRU/SFU, 4 AC Power(Power Cords Cable), without
Software Charge and Document)

13



ME0P08SFUE70

ME60-X8 200G SFU Bundle Configuration(Including 2*SRUA5 and 1*SFUI-200-C)

14



ME0P08SFUE71

ME60-X8 200G Hardware Upgrade Bundle(Including 2*B5 SRUs,1*SFU)

15



ME0P08BASA72

ME60-X8 Basic Configuration (Including ME60-X8 Chassis. 2+1 Redundant 100G SRU/SFU. 4 AC Power. without Software Charge and
Document)

16



ME0P08BASD72

ME60-X8 Basic Configuration (Including ME60-X8 Chassis. 2+1 Redundant 100G SRU/SFU. 4 DC Power. without Software Charge and
Document)

17



ME0P08BASA30

ME60-X8 Basic Configuration (Including ME60-X8 Chassis.2+1 Redundant SRU/SFU.2 PFUs.4 AC Power.without Software Charge and
Document)

18



ME0P08BASD30

ME60-X8 Basic Configuration (Including ME60-X8 Chassis.2+1 Redundant SRU/SFU.4 DC Power.without Software Charge and Document)

19



ME0P08SFUF70

ME60-X8 100G SFU Bundle Configuration(Including 2*SRUs.1*SFU)

20



ME0P16BASA32

ME60-X8 Basic Configuration (Including ME60-X8 Chassis.2+1 Redundant SRU/SFU.4 AC Power.without Software Charge and Document)

21



ME0P16BASD32

ME60-X8 Basic Configuration (Including ME60-X8 Chassis.2+1 Redundant SRU/SFU.4 DC Power.without Software Charge and Document)

22



ME0B0BKP0871

ME60-X8A Integrated Chassis DC Components(Including 2 Fan Tray)

23



ME0B0BKP0872

ME60-X8A Integrated Chassis AC Components(Including 2 Fan Tray)

24



ME0B0BKP0873

ME60-X8A Integrated Chassis HVDC Components (Including 2 Fan Tray)

25



ME0D0SRUA470

ME60-X8 Switch and Route Processing Unit A4

26



ME0DSFUI407C

ME60-X8 Switch Fabric Unit C

27



ME0B0BKP0830

ME60-X8 Integrated Chassis Components (Including 4 DC Power)

ME0P08BASA70 Specifications

ME0P08BASA70 Specifications



Switching Capacity

12.58 Tbit/s

Slots

11 slots, including 2 SRUs (1:1 backup), 1 SFUs (2+1 backup), and 8 LPUs

Dimensions (W x D x H)

442 mm x 650 mm x 620 mm (14U)

Maximum Power Consumption

2,340W (120G)
4,100W (240G)

Full Configuration Weight

119 kg (120G)
136 kg (240G)

Interface Types

OC-192c/STM-64c POS OC-48c/STM-16c POS
OC-3c/STM-1c POS OC-12c/STM-4c ATM
OC-3c/STM-1c ATM 100GE-WAN/LAN
10GE-WAN/LAN GE/FE E3/CT3 CE1/CT1

BRAS

User access protocol: PPPoE, PPPoEoA, IPoE, IPoEoA, and PPPoA 802.1X
User authentication protocol: PAP, CHAP, MSCHAP, RADIUS, and HWTACACS
User accounting protocol: RADIUS, HWTACACS, and COPS
User authorization protocol: RADIUS, HWTACACS, and COPS
Policy protocol: COPS and COA

L2TP

Session number: up to 64K/per slot, up to 128K/per chassis
Tunnel number: up to 16K/per slot, up to 12K/per chassis

IPv4

Static routing protocol and dynamic routing protocols such as RIP, OSFP, IS-IS, and BGP-4

IPv6

Various technologies for transition from IPv4 to IPv6:
Manual tunnel configuration, automatic tunnel configurations, IPv6-to-IPv4(6-to-4)
Tunneling, Generic Routing Encapsulation (GRE) tunneling, and Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) tunneling
IPv4 over IPv6 tunneling and IPv6 provider Edge Router (6PE).
IPv6 static routing protocol
IPv6 dynamic routing protocols such as RIP Next Generation (RIPng), OSPFv3, IS-ISv6, and BGP4+.
IPv6 neighbor discovery and psth Maximum Transmission Unit (PMTU) discovery.
Transmission Control Protocol Version 6(TCP6), ping IPv6, traceroute IPv6,socket IPv6, static IPv6 Domain Name System(DNS),
specifying the IPv6 DNS server, Trivial File Transfer Protocol(TFTP) IPv6 dient, and IPv6 policy-based routing
Internet Control Message Protocol Version 6(ICMPv6) Management Information Base (MIB),User Datagram Protocol Version 6(UDP6)
MIB,ICP6 MIB, AND IPv6 MIB

MPLS

LDP over TE, VPLS, H-VPLS, policy-based routing inVPN.
MPLS L2VPNs in either Martini or Kompella mode.
VLL/VPLS access L3VPNs.QinQ, MPLS/BGP L3VPN, and inter-AS VPN Option A/B/C.Asynchronous Transfer Mode(ATM)E1, Inverse Multiplexing over ATM(IMA), and Time-Division Multiplexing(TDM)PWE3.MPLS-TP.

Layer 2 feature

IEEE802.1q, IEEE802.1p, IEEE802.3ad, and IEEE802.1ab.
Spanning Tree Protocol(STP), Rapid Spanning Tree Protocol (RSTP),Multiple Spanning Tree Protocol (MSTP), RPPP, DHCP+ VLAN switching, and user binding.

QoS

Weighted Random Early Detection (WRED), DS-TE capability with a maximum of eight CTs, five-level H-QoS scheduling, VLL/PWE3 QoS, and MPLS H-QoS.
The last mile QoS. Multicast replication of IPoE access users

CGN

NAT444,NAT64
Distributed deployment or integrated deployment
Re-allocation or dynamic allocation of ports
VPN NAT NAT ALG(TFP/ICMP/PPTP/RTSP/SIP)
Port forwarding NAT server
Web user's anthentication DS-Lite L2-Aware NAT

DAA

ME60s support Destination Address Accounting (DAA), providing refined subscriber management with differentiated service and in IP networks.
The Huawei Multi-Service Control Gateways ME0P08BASA70 Basic Configuration Incl. ME60-X8 Chassis, 2+1 200G Redundant SRU/SFUI-200-C, 4*AC is a sensational customer favorite, and we hope you like it just as much.
