Huawei HiSecEngine USG6600E-AC firewall(fixed-configuration) USG6655E AC Host(16*GE RJ45, 12*10GE SFP+, 2*40GE QSFP+,32G Memory,2*AC
SPECIFICATIONS
Brand Name: HUAWEI
High-concerned Chemical: None
Products Status: Stock
Type: Wired
VPN Support: Yes
Throughput: 80 Gbit/s
Simultaneous Sessions: 12000000
Brand Name: HUAWEI
Model Number: USG6655E-AC
Product name: USG6655E-AC
Dimension (W*D*H, mm): 43.6 x 442 x 420
Interfaces: 2 x 40GE (QSFP+) + 12 x 10GE (SFP+) + 16 x GE*
Virtual Firewalls: 1000
Weight: 7.6kg
Firewall Throughput: 40Gbit/s
Warranty: 1 Year
Certification: FCC,CCC,CE
Description
Huawei HiSecEngine USG6600E-AC firewall(fixed-configuration) USG6655E AC Host(16*GE RJ45, 12*10GE SFP+, 2*40GE QSFP+,32G Memory,2*AC
USG6655E/-AC HW Security Gateway Enterprise high-end firewall comes with 40GE 10GE ports
USG6655E AC Host (2*40GE (QSFP+) + 12*10GE (SFP+) +16*GE, 2 AC power supplies)
HW HiSecEngine USG6600E series next-generation firewalls are designed for medium- and large-sized enterprises, institutions,and next-generation data centers. USG6600E firewalls provide NGFW capabilities and collaborate with other security devices toproactively defend against network threats, enhance border detection capabilities, and resolve performance deterioration problems.They provide pattern matching and encryption/decryption service processing acceleration capabilities, which greatly improve the performance of firewalls, security detection, and IPSec services.
Specifications
Item |
Description |
---|---|
System specifications |
|
CPU |
Multi-core 1.0 GHz processor |
Memory |
DDR3 4 GB |
Flash |
16 MB |
CF card |
2 GB |
Hard disk |
Optional hot-swappable 300GB 2.5-inch SAS hard disks |
SPUB (the service engine) |
Not supported |
Dimensions and weight |
|
Dimensions (Hb x Wa x D) |
44.4 mm x 442 mm x 421 mm |
Weight |
Standard: 6 kg Fully configured: 10 kg |
Power specifications |
|
AC power |
Supported; 150 W built-in power module (default) and 170 W hotswappable power module (optional) |
Rated input voltage (AC) |
100 V to 240 V, 50 Hz/60 Hz |
Maximum input voltage (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
Maximum input current (AC) |
2.5 A |
DC power |
Not supported. |
Maximum output power |
150 W (default) or 170 W (optional) |
Heat dissipation |
|
Fan module |
Built-in fan module, cannot be removed. |
Air flow (hot air flow, viewed facing the rear panel) |
Intake on the front and left sides, exhaust on the right side |
Port density |
|
Out-of-band management port |
1 (RJ45) |
Console port |
1 (RJ45) |
USB 2.0 port |
1 |
Mandatory service ports |
|
Expansion slot |
2×WSIC |
Types of expansion cards |
|
