H3C LS-S5820V2-52QF 48 10 Gigabit optical ports 4 QSFP ports Layer 3 data Ethernet switch, 1.28Tbps/11.52Tbps back plane bandwidth

R 108,015.95
R 108,015.95
R 105,977.95
Sold out
Shipping calculated at checkout.

H3C LS-S5820V2-52QF 48 10 Gigabit optical ports 4 QSFP ports Layer 3 data Ethernet switch, 1.28Tbps/11.52Tbps back plane bandwidth

SPECIFICATIONS

Brand Name: H3C

High-concerned Chemical: None

DIY Supplies: ELECTRICAL

Certification: CE

Products Status: Stock

Ports: 48

Transmission Rate: 10/100Mbps

Function: LACP, QoS, SNMP, Stackable, VLAN Support

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 1.28Tbps

Brand Name: H3C

Model Number: LS-S5820V2-52QF

Product Name: LS-S5820V2-52QF

Warranty: 1 Year

LS-S5820V2-52QF H3C 48 10 Gigabit optical ports 4 QSFP ports Layer 3 data Ethernet switch

Description

The H3C S5820V2 series switch is a data center-level Ethernet switch product independently developed by H3C. As a part of the H3C Virtual Converged Framework (VCF), it greatly simplifies the data center network structure through an innovative architecture and provides high-density 10GE On the basis of /40GE wire-speed forwarding port, it also supports flexible modular programmability and rich data center features. H3C S5820V2 series switches are positioned for high-density access in next-generation data centers and cloud computing networks, and can also be used in the core or convergence of enterprise networks and metropolitan area networks.

High-density 10G access

As user-side bandwidth continues to increase, switches need to provide higher forwarding performance and 10-Gigabit port expansion capabilities. S5820V2-52Q supports 48 10G Base-T ports and 4 40G QSFP+ ports; S5820V2-52QF and S5820V2-52QF-U support 48 SFP+ 10G/Gigabit adaptive optical ports and 4 QSFP+ ports; S5820V2-48S supports 48 SFP+ 10G/Gigabit adaptive optical ports; S5820V2-54QS-GE supports 4 SFP+ 10G/Gigabit adaptive optical ports and 2 QSFP+ ports, each QSFP+ port can be converted to 4 wire-speed forwarding SFP+ 10G optical ports. Therefore, the S5820V2 series switches can support up to 48 or 64 10 Gigabit ports, meeting the data center's demand for high-density 10 Gigabit access.

Specifications

Product number

LS-S5820V2-52QF
Product type

10 Gigabit Ethernet switch
Backplane bandwidth

1.28Tbps/11.52Tbps
Packet forwarding rate

960Mpps
Transmission rate

10/100/1000/10000Mbps
Management port

1 Console port, 1 management Ethernet port, 1 USB port
Stacking support

Stackable
QoS support

Supports limit on the rate of receiving and sending messages on the port;

supports CAR function; each port supports 8 output queues; supports flexible queue scheduling algorithms, which can be set based on ports and queues at the same time,

supports SP, WDRR , WFQ, SP+WDRR, SP+WFQ five modes; support 802.1p and DSCP priority re-marking of packets; s

upport L2 (Layer 2) ~ L4 (Layer 4) packet filtering function, provide based on source MAC address, destination MAC address, source IP (IPv4/IPv6) address, destination IP (IPv4/IPv6) address, port, protocol, VLAN flow classification;

support time range (Time Range);

support WRED (Weighted Random Early Detection, weighted random early detection) )
VLAN support

Support port-based VLAN (4094)
Network management function

Support command line interface (CLI) configuration;

support Telnet remote configuration;

support configuration through the console port;

support SNMP; support IMC network management system; support system log;

support hierarchical alarm;

support NTP;

support power alarm function;

support fan and temperature alarm ;

Support debugging information output;

support Ping, Tracert;

support Track;

support Telnet remote maintenance
Cyber security

Support user hierarchical management and password protection Support AAA authentication

Support RADIUS authentication

Support HWTACACS

Support SSH 2.0

Support port isolation

Support IP+MAC+ port binding

Support IP Source Guard

Support HTTPs

Support SSL

Support PKI (Public Key Infrastructure, public key infrastructure) Support bootrom access control (password recovery)
Voltage

Rated voltage range: 100V-240V AC, 50/60Hz;

Maximum voltage range: 90V-264V AC, 47/63Hz;

Rated voltage range: -40V~-60V DC;

Maximum voltage range: -40V~-72V DC
Maximum power

Power consumption (static): 343W;

power consumption (at full load): 366W
Dimensions

440×700×43.6mm
Weight

≤13.5Kg

Life is too short to live without the H3C LS-S5820V2-52QF 48 10 Gigabit optical ports 4 QSFP ports Layer 3 data Ethernet switch, 1.28Tbps/11.52Tbps back plane bandwidth. Be happy. Be Content. Be Satisfied.

Inventory Last Updated: Apr 10, 2025
