Fortinet NGFW Middle-range Series FortiGate Firewall 2x 10GE SFP+ 8x GE SFP slots, 8x GE RJ45 ports 1x GE RJ45 management ports 501E

Regular price: R 286,092.27
Sale price: R 286,092.27
Regular price: ~~R 379,622.44~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

SPECIFICATIONS

Available PoE Power: None

Brand Name: FORTINET

Condition: NIB

DIY Supplies: Electrical

Forwarding Performance: 41.66Mpps

High-concerned chemical: None

Maximum stacking number: 10x GE RJ45 ports (including 1x MGMT port, 1x HA port, 8x switch ports

Number of AP per switch/stack: 50

Ports: 2x 10 GE SFP+ slots

Stack Bandwidth: 160 Gpbs

Details: 8 x GE SFP slots 8 x GE RJ45 ports 1 x GE RJ45 management ports

Interface: 2 x 10GE SFP+ slots

Product Overview

FG-501E is the Fortinet NGFW Middle-range Series FortiGate 501E firewall. The FortiGate 501E series delivers next generation firewall capabilities for mid-sized to large enterprises, with the flexibility to be deployed at the campus or enterprise branch.

Quick Spec
Sku	FG-501E
Firewall	36 Gbps
IPS	5.5 Gbps
NGFW	5 Gbps
Threat Protection	4.7 Gbps
Interfaces	2 x 10GE SFP+ slots 8 x GE SFP slots 8 x GE RJ45 ports 1 x GE RJ45 management ports

Figure 2 shows the rear view of FG-500E. FG-501E is similar with it.

Optional Accessories & Spares	SKU	Description
1 GE SFP LX Transceiver Module	FG-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots
1 GE SFP RJ45 Transceiver Module	FG-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots
1 GE SFP SX Transceiver Module	FG-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Short Range	FG-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Long Range	FG-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Active Direct Attach Cable, 10m / 32.8 ft	SP-CABLE-ADASFP+	10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots
Optional Power Supply	SP-FG300E-PS	AC power supply for FG-300/301E, FG-400/401E, FG-500/501E, FG-600/601E, FAZ-200F/300F/800F and FMG-200F/300F

Table 3 shows the bundle models and licenses of FG-501E.

Types	Model	Description
Basic Firewall	FG-501E	2x 10 GE SFP+ slots, 10x GE RJ45 ports (including 1x MGMT port, 1x HA port, 8x switch ports), 8x GE SFP slots, SPU NP6 and CP9 hardware accelerated, 2x 240 GB onboard SSD storage
1 year bundle	FG-501E-BDL-950-12	FG-501E Hardware plus 1 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-501E & FC-10-0501E-950-02-12)
1 year License	FC-10-0501E-950-02-12	1 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-501E
3 year bundle	FG-501E-BDL-950-36	FG-501EHardware plus 3 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-501E & FC-10-0501E-950-02-36)
3 year License	FC-10-0501E-950-02-36	3 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-501E
5 year bundle	FG-501E-BDL-950-60	FG-501EHardware plus 5 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-501E & FC-10-0501E-950-02-60)
5 year License	FC-10-0501E-950-02-60	5 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-501E
Power supply	SP-FG300E-PS	AC power supply for FG-300/301E and FG-500/501E.

The Fortinet NGFW Middle-range Series FortiGate Firewall 2x 10GE SFP+ 8x GE SFP slots, 8x GE RJ45 ports 1x GE RJ45 management ports 501E was built with people like you in mind. Something to keep you happy. Every. Single. Day.
