CloudEngine S5735-L series S5735-L24T4S-A1 Networking Ethernet 10/100/1000M 24 Port Switch, 2410/100/1000BASE-T, 4GE SFP, AC power

Regular price: R 17,456.95
Sale price: R 17,456.95
Regular price: ~~R 17,695.95~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

CloudEngine S5735-L series S5735-L24T4S-A1 Networking Ethernet 10/100/1000M 24 Port Switch, 24*10/100/1000BASE-T, 4*GE SFP, AC power

SPECIFICATIONS

Brand Name: HUAWEI

Shape: 1

Material: Acrylic

High-concerned Chemical: None

Size: 1

Products Status: Stock

Ports: 24

Transmission Rate: 10/100/1000Mbps

Function: LACP, SNMP, Stackable, VLAN Support, LACP, Stackable, VLAN Support

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 56Gbps/336Gbps, 56Gbps/336Gbps

Model Number: CloudEngine S5735-L24T4S-A1

Product Name: CloudEngine S5735-L series S5735-L24T4S-A1 Network Ethernet Switch

chassis height: 1U

Heat Dissipation: Intelligent heat dissipation

color: black or any

IP Routing: Static route, RIP, RIPng, OSPF, OSPFv3

Condition: 100% Original Brand

Forwarding Performance: 42Mpps

Products Description

CloudEngine S5735-L series S5735-L24T4S-A1 Networking Ethernet 10/100/1000M 24 Port Switch, 24*10/100/1000BASE-T, 4*GE SFP, AC power

CloudEngine S5735-L Series Switches
CloudEngine S5735-L is a series of simplified gigabit access switches that provide 12–48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink ports.
CloudEngine S5735-L series switches are designed for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Versatile Routing Platform (VRP), CloudEngine
S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols - providing higher performance and more powerful service processing capabilities for networks.

Specifications

CloudEngine S5731-L Series

Product Model	CloudEngine S5735-L12T4S-A CloudEngine S5735-L12P4S-A	CloudEngine S5735-L24T4S-A CloudEngine S5735-L24P4S-A	CloudEngine S5735-L24T4X-A CloudEngine S5735-L24T4X-D CloudEngine S5735-L24P4X-A	CloudEngine S5735-L48T4S-A	CloudEngine S5735-L48T4X-A CloudEngine S5735-L48P4X-A	CloudEngine S5735-L32ST4X-A CloudEngine S5735-L32ST4X-D
Forwarding Performance	24 Mpps	42 Mpps	96 Mpps	78 Mpps	132 Mpps	108 Mpps
Switching Capacity2	32 Gbps/336 Gbps	56 Gbps/336 Gbps	128 Gbps/336 Gbps	104 Gbps/432 Gbps	176 Gbps/432 Gbps	144 Gbps/432 Gbps
Fixed Ports	12 x 10/100/1000Base-T ports, 4 x GE SFP ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports	24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports	48 x 10/100/1000BASE-T ports, 4 x GE SFP ports	48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports	24 x GE SFP ports, 8 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports
PoE+	CloudEngine S5735-L12P4S-A: Supported CloudEngine S5735-L24P4S-A: Supported CloudEngine S5735-L24P4X-A: Supported CloudEngine S5735-L48P4X-A: Supported Other: Not support						supported	Not supported	supported	Not supported
M AC Features	M AC address auto-learning and aging Static, dynamic, and blackhole MA C address entries Packet filtering based on source M AC addresses Interface-based M AC address learning limiting
VLAN Features	4094 VLANs Guest VLAN, Voice VLAN GVRP MUX VLAN VLAN assignment based on M AC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping
IP Routing	Static route, RIP, RIPng, OSPF, OSPFv3
Super Virtual Fabric (SVF)	Plug-and-play SVF clients Automatic software package and patch loading to SVF clients One-click and automatic delivery of service configurations Independent SVF client operations
Interoperability	VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP)

Modle	CloudEngine S5735-L8T4S-A1 CloudEngine S5735-L8P4S-A1	CloudEngine S5735-L8T4X-A1 CloudEngine S5735-L8P4X-A1	CloudEngine S5735-L24T4S-A1 loudEngine S5735-L24P4S-A1	CloudEngine S5735-L24T4X-A1/D1 CloudEngine S5735-L24P4X-A1	CloudEngine S5735-L48T4S-A1 CloudEngine S5735-L48P4S-A1	CloudEngine S5735-L48T4X-A1 CloudEngine S5735-L48P4X-A1
Forwarding Performance	18 Mpps	72 Mpps	42 Mpps	96 Mpps	78 Mpps	132 Mpps
Switching Capacity2	24 Gbps/336 Gbps	96 Gbps/336 Gbps	56 Gbps/336 Gbps	128 Gbps/336 Gbps	104 Gbps/432 Gbps	176 Gbps/432 Gbps
Fixed Ports	8 x 10/100/1000Base-T ports, 4 x GE SFP ports	8 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports	24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports	48 x 10/100/1000BASE-T ports, 4 x GE SFP ports	48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports
PoE+	CloudEngine S5735-L8P4S-A1: Support CloudEngine S5735-L8P4X-A1: Support CloudEngine S5735-L24P4S-A1: Support CloudEngine S5735-L24P4X-A1: Support CloudEngine S5735-L48P4S-A1: Support CloudEngine S5735-L48P4X-A1: Support Other models: Not support
M AC Features	M AC address auto-learning and aging Static, dynamic, and blackhole M AC address entries Packet filtering based on source M AC addresses Interface-based M AC address learning limiting
VLAN Features	4094 VLANs Guest VLAN, Voice VLAN GVRP MUX VLAN VLAN assignment based on M AC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping
IP Routing	Static route, RIP, RIPng, OSPF, OSPFv3
Super Virtual Fabric (SVF)	Plug-and-play of SVF clients Automatic software package and patch loading to SVF clients One-click and automatic delivery of service configurations Independent SVF client running
Interoperability	VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP)

Technical Specifications

Technical specifications of the S5735-L24T4S-A1

Item	Specification
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U]	1 U
Chassis material	Metal
Weight without packaging [kg(lb)]	2.45 kg (5.4 lb)
Weight with packaging [kg(lb)]	3.34 kg (7.36 lb)
Typical power consumption [W]	32.7 W
Typical heat dissipation [BTU/hour]	111.58 BTU/hour
Maximum power consumption [W]	47.6 W
Maximum heat dissipation [BTU/hour]	162.42 BTU/hour
Static power consumption [W]	18.4 W
MTBF [years]	66.16 years
MTTR [hours]	2 hours
Availability	> 0.99999
Noise at normal temperature (acoustic power) [dB(A)]	39 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]	27.2 dB(A)
Number of card slots	0
Number of power slots	0
Number of fans modules	1
Redundant power supply	Not supported
Long-term operating temperature [°C(°F)]	-5°C to +50°C (23°F to 122°F) (0 m to 1800 m altitude, non-industrial optical modules) -5°C to +55°C (23°F to 131°F) (0 m to 1800 m altitude, industrial optical modules with transmission distances less than or equal to 10 km)
Restriction on the operating temperature variation rate [°C(°F)]	When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature ranges from -5°C to +45°C (23°F to 113°F) when optical modules with transmission distances greater than or equal to 70 km are used.
Storage temperature [°C(°F)]	-40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity [RH]	5% to 95%, noncondensing
Long-term operating altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Power supply mode	AC built-in
Rated input voltage [V]	AC input: 100 V AC to 240 V AC; 50/60 Hz High-voltage DC input: 110 V DC to 250 V DC
Input voltage range [V]	AC input: 90 V AC to 264 V AC; 47 Hz to 63 Hz High-voltage DC input: 88 V DC to 300 V DC
Maximum input current [A]	2 A
Memory	512 MB
Flash memory	512 MB
Console port	RJ45
Eth Management port	Not supported
USB	Not supported
RTC	Not supported
RPS input	Not supported
Service port surge protection [kV]	Common mode: ±7 kV
Power supply surge protection [kV]	±6 kV in differential mode, ±6 kV in common mode
Ingress protection level (dustproof/waterproof)	IP20
Types of fans	Built-in
Heat dissipation mode	Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction	Air intake from left and front, air exhaustion from right
PoE	Not supported
Certification	EMC certification Safety certification Manufacturing certification

The CloudEngine S5735-L series S5735-L24T4S-A1 Networking Ethernet 10/100/1000M 24 Port Switch, 24*10/100/1000BASE-T, 4*GE SFP, AC power destined to impress, and priced at only R 17,456.95, for a limited time.
