Cisco Nexus 9300 with 48p 10G BASE-T and 6p 40G/100G QSFP28, MACsec 48 Ports Network Ethernet Switch 2.16 Tbps bandwidth N9K-C93108TC-FX

Cisco Nexus 9300 with 48p 10G BASE-T and 6p 40G/100G QSFP28, MACsec 48 Ports Network Ethernet Switch 2.16 Tbps bandwidth N9K-C93108TC-FX

R 233,509.24
R 233,509.24
R 281,973.42
Sold out
Shipping calculated at checkout.

Cisco Nexus 9300 with 48p 10G BASE-T and 6p 40G/100G QSFP28, MACsec 48 Ports Network Ethernet Switch 2.16 Tbps bandwidth N9K-C93108TC-FX

Description

The Cisco Nexus 93108TC-FX Switch is a 1RU switch that supports 2.16 Tbps of bandwidth and over 1.25bpps. The 48 10GBASE-T downlink ports on the 93108TC-FX can be configured to work as 100-Mbps, 1-Gbps, or 10-Gbps ports. The uplink can support up to six 40- and 100-Gbps ports, or a combination of 1-, 10-, 25-, 40, 50-, and 100-Gbps connectivity, offering flexible migration options.

Product Features

The Cisco Nexus 9300-FX series features and benefits:

  • ● Architectural Flexibility
  • ● High Scalability, Flexibility, and Security
  • ● Intelligent Buffer Management
  • ● RDME over Converged Ethernet – RoCE Support
  • ● LAN and SAN Convergence
  • ● Hardware and Software High Availability
  • ● Purpose-Built Cisco NX-OS Software Operating System with Comprehensive, Proven Innovations
  • ● Cisco Network Assurance Engine (NAE)

Quick Spec

Model N9K-C93108TC-FX
Physical dimensions
(H x W x D)		 1.72 x 17.3 x 22.5 in.
(4.4 x 43.9 x 57.1 cm)
MTBF 319,790 hours
CPU 4 cores
System memory 24 GB

Compare to Similar Items

Model

Description

Cisco Nexus 93180YC-FX

48 x 1/10/25-Gbps fiber ports and 6 x 40/100-Gbps QSFP28 ports

Cisco Nexus 93108TC-FX

48 x 100M/1/10GBASE-T ports and 6 x 40/100-Gbps QSFP28 ports

Cisco Nexus 9348GC-FXP

48 x 100M/1G BASE-T ports, 4 x 1/10/25-Gbps SFP28 ports and 2 x 40/100-Gbps QSFP28 ports

Product Specifications

Model: N9K-C93108TC-FX

Brand: Cisco

Switch Series: Cisco Nexus 93108TC-FX

Port Configuration: 48 x 100M/1/10GBASE-T RJ45, 6 x 40/100G QSFP28

Downlink Speeds: 100Mbps, 1Gbps, 10Gbps

CPU: 4-core processor

System Memory: 24GB

Storage: 128GB SSD

Packet Buffer: 40MB

Management Interfaces: 2 management ports (1 x RJ-45, 1 x SFP+), 1 x USB, 1 x RS-232 serial console

Power Supplies: Dual 500W AC / 930W DC / 1200W HVAC / HVDC

Typical Power Consumption: 276W (AC/DC)

Max Power Consumption: 460W (AC/DC)

Input Voltage Ranges: AC: 100–240V, HVAC: 200–277V, DC: -48V to -60V, HVDC: -240V to -380V

Frequency: 50–60Hz

Dimensions: 1.72 x 17.3 x 22.5 in (4.4 x 43.9 x 57.1 cm)

Cooling: 4 fan modules (port-side airflow)

Noise Level: 64.2 dBA @40% fan, 68.9 dBA @70% fan, 77.8 dBA @100% fan

Operating Temperature: 0°C to 40°C (32°F to 104°F)

Storage Temperature: -40°C to 70°C (-40°F to 158°F)

Humidity: 5–95% non-condensing

Altitude: 0–4,000m

MTBF: 319,790 hours

RoHS Compliance: Yes (RoHS6)

Safety Certifications: UL 60950-1, EN 60950-1, IEC 60950-1

Minimum NX-OS Version: NXOS-703I7.1

Minimum ACI Version: ACI-N9KDK9-12.2A

Nexus N9K-C93108TC-FX 48 Ports Network Ethernet Switch

SKU

N9K-C93108TC-FX

CPU

4 cores

System memory

24 GB

SSD drive

128 GB

System buffer

40 MB

Management ports

2 ports: 1 RJ-45 and 1 SFP+

USB ports

1

RS-232 serial ports

1

Power supplies (up to 2)

500W AC, 930W DC, or 1200W HVAC/HVDC

RS-232 serial ports

1



Every product is unique, just like you. If you're looking for a product that fits the mold of your life, the Cisco Nexus 9300 with 48p 10G BASE-T and 6p 40G/100G QSFP28, MACsec 48 Ports Network Ethernet Switch 2.16 Tbps bandwidth N9K-C93108TC-FX is for you.

Inventory Last Updated: Nov 08, 2025
