Cisco Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE, Ethernet Switch C9300-24UX-A, C9300-24P-E, C9300-24P-A

Cisco Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE, Ethernet Switches C9300-24UX-A, C9300-24P-E, C9300-24P-A

Description

C9300-24UX-A

Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE, Network Advantage

The Cisco C9300-24UX-A is an advanced enterprise-grade switch designed to meet the high demands of network professionals. This switch integrates seamlessly into complex network environments, offering unmatched reliability and security. As part of Cisco's C9300 series, the C9300-24UX-A is built to deliver exceptional performance with extensive network protocol support.

Compare to Similar Items

Optional Add-ons

C9300-24P-E

Catalyst 9300 24-port 1G copper with modular uplinks, PoE+, Network Essentials

The Cisco C9300-24P-E is a high-performance enterprise switch designed for modern network requirements. Ideal for businesses of all sizes, this switch from the renowned Cisco brand provides excellent connectivity options and powerful networking features. The C9300-24P-E switch supports advanced Layer 2 and Layer 3 capabilities, ensuring robust network efficiency and management. It incorporates PoE+ ports, which are integral for powering various devices like IP phones and wireless access points, making it suitable for versatile networking environments. The Cisco 9300 series ensures high availability with stack-able switches and redundant power supplies, delivering unparalleled network resilience and flexibility.

Compare to Similar Items

C9300-24P-A

Catalyst 24-port 1G copper PoE+ switch with modular uplinks, designed for secure and scalable enterprise networking with Network Advantage features.

The Cisco Catalyst 9300 Series Switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-24P-A is 24-port PoE+, Network Advantage Switch of 9300 series. Catalyst 9300 Series are the next generation of the industry’s most widely deployed switching platform. At 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density 802.11ac Wave2.

Quick Spec

C9300-24UX-A Specification

Technical Specifications

Model: C9300-24UX-A

Brand: Cisco

Product Description:

Catalyst 9300 24-port Multigigabit Ethernet and UPOE, Network Advantage

Total Multigigabit copper ports:

24 Multigigabit Cisco UPOE (100 Mbps or 1, 2.5, 5, or 10 Gbps)

Default AC power supply: 1100W AC

Available PoE power: 490W

Cisco StackWise-480: Yes

Cisco StackPower: Yes

Default power supply: PWR-C1-1100WAC

Switching capacity: 640 Gbps on 24-port Multigigabit Ethernet model

Stacking bandwidth: 480 Gbps

Total number of MAC addresses: 32,000

Total number of IPv4 routes:

32,000 (24,000 direct routes and 8,000 indirect routes)

IPv4 routing entries: 32,000

IPv6 routing entries: 16,000

Multicast routing scale: 8,000

QoS scale entries: 5,120

ACL scale entries: 5,120

Packet buffer per SKU: 32 MB buffer for 24-port Multigigabit

FNF entries: 128,000 flows on 24-port Multigigabit

DRAM: 8 GB

Flash: 16 GB

VLAN IDs: 4,000

Total Switched Virtual Interfaces (SVIs): 2,000

Jumbo frames: 9,198 bytes

Total routed ports per 9300 Series stack: 208

Wireless bandwidth per switch:

Up to 48 Gbps on 24-port Gigabit Ethernet model

Forwarding rate: 154.76 Mpps

Dimensions (H x W x D):

1.73 x 17.5 x 17.5 inches

Mean time between failures (hours): 299,000

Safety certifications:

UL 60950-1, CAN/CSA-C222.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1, IEEE 802.3

Electromagnetic emissions certifications:

47 CFR Part 15, CISPR22 Class A, EN 300 386 V1.6.1, EN 55022 Class A, EN 55032 Class A, CISPR 32 Class A, EN61000-3-2, EN61000-3-3, ICES-003 Class A, TCVN 7189 Class A, V-3 Class A, CISPR24, EN 300 386, EN55024, TCVN 7317

Environmental:

Reduction of Hazardous Substances (ROHS) 5
