Cisco Catalyst 2960-24PC L2 Switch, 2410/100 PoE Ports, 2T/SFP, LAN Base Image WS-C2960+24PC-L Gigabit Ethernet Enterprise Switch

Regular price: R 49,643.95
Sale price: R 49,643.95
Regular price: ~~R 50,597.95~~
Unit price: per

Shipping calculated at checkout.

Default Title

Quantity must be 1 or more

Cisco Catalyst 2960-24PC L2 Switch, 24*10/100 PoE Ports, 2*T/SFP, LAN Base Image WS-C2960+24PC-L Gigabit Ethernet Enterprise Switches

SPECIFICATIONS

Brand Name: CISCO

DIY Supplies: ELECTRICAL

Certification: CE

Certification: DOT

Certification: EAC

Certification: EPA

Certification: FCC

Certification: GMP

Certification: RoHS

Certification: TGA

Certification: UL

Certification: KC

Certification: pse

Certification: weee

Certification: none

Products Status: Stock

Ports: 24

Transmission Rate: 10/100/1000Mbps

Function: LACP, QoS, SNMP, Stackable, VLAN Support

Communication Mode: Full-Duplex & Half-Duplex

Switch Capacity: 56Gbit/s

Model Number: WS-C2960+24PC-L

Product Name: WS-C2960L-24TS-LL

Warranty: 1 Year

2960-L Series WS-C2960L-24TS-LL 24 Gigabit Ethernet ports + 2 SFP Layer 2 Enterprise Ethernet Switches

Overview

WS-C2960L-24TS-LL offering 24 x GigE ports, 4 x 1G SFP and LAN Lite, is one of the 2960-L Series Switches. These 2960-L switches are fixed configuration, Gigabit Ethernet switches that provide entry-level enterprise-class Layer 2 access for branch offices, conventional workspaces, and out-of-wiring closet applications. Designed for operational simplicity to lower total cost of ownership, they enable secure and energy-efficient business operations with a range of IOS Software features. There is an Asia Pacific Part number: WS-C2960L-24TS-AP. It is the same as the WS-C2960L-24TS-LL.

Quick Spec of the WS-C2960-24PC-L

Product Code	WS-C2960-24PC-L
Enclosure Type	Rack-mountable - 1U
Feature Set	LAN Base
Uplink Interfaces	2 dual-purpose (10/100/1000 or SFP) ports
Ports	24 x Ethernet 10/100 PoE ports
Throughput	6.5 Mpps
Backplane Capacity	16 Gbps
DRAM	64 MB
Dimensions	1.73 x 17.5 x 9.3 in.
Package Weight	9.5 Kg

Specifications

Main parameters
The product type	Gigabit Ethernet switch
Transfer rate	10/100/1000Mbps
Interchange mode	Store-forward
Packet forwarding rate	68.5Mbps
Switching bandwidth	56 Gbps

Port parameters
Port structure	Non-modular
The number of ports	24 pcs
Port description	24 Gigabit Ethernet ports
Control port	2 SFPs

Features
Network standards	IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1X,IEEE 802.1ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3x,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z

Other parameters
Product size	445×279×45mm
Product weight	3.7kg
Environmental standards	Working temperature: 0-45 °C Operating humidity: 10%-85% (non-condensing) Storage temperature: -25-70°C Storage humidity: 10%-85% (non-condensing)
Other parameters	On-board memory: 512MB

Annex
Packing list	WS-C2960X-24TS-LL Switch x1 Power Cord x1

The Accessories of the WS-C2960-24PC-L

Models	Description
GLC-LH-SM	GE SFP, LC connector LX/LH transceiver
GLC-SX-MMD	1000BASE-SX SFP transceiver module, MMF, 850nm, DOM
CAB-CONSOLE-RJ45	Console Cable 6ft with RJ45 and DB9F

Compare to Similar Items

Comparison of similar items

Models	WS-C2960-24PC-L	WS-C2960-24TC-L
PoE Available	Yes	N/A
Ports	24 x Ethernet 10/100 PoE ports	24 x Ethernet 10/100 ports
Uplinks	2 dual-purpose uplinks	2 dual-purpose uplinks
Feature Set	LAN Base	LAN Base

Technical Specifications

WS-C2960-24PC-L Specification
Topology	Ethernet (10/100BaseTX) Ethernet (10/100/1000BaseT) Gigabit Ethernet (SFP)
Maximum Port density	24 10/100 PoE ports
Uplinks	2 dual-purpose (10/100/1000 or SFP) ports
Modular/Expansion Slots	n/a
Architecture	Layer 2 Switching (basic connectivity), Layer 2 Switching (intelligent services), Voice Enabled
Form Factor	Fixed, Rack Mountable, Standalone/Clustering
Dimensions	1.73 x 17.70 x 13.07 in.
Weight	12 Pounds
MTBF in thousands of hours	382
DRAM	64 MB
Maximum Number of PoE (IEEE 802.3af) Ports*	24 ports up to 15.4W
Available PoE Power	370W
10/100 Ethernet Interfaces	24
Uplink Interfaces	2 (SFP or 1000BASE-T)
Cisco IOS Software Feature Set	LAN Base
Flash memory	64 MB
DRAM	128 MB
Forwarding bandwidth	16 Gbps
Maximum active VLANs	255
VLAN IDs available	4K
Maximum transmission unit (MTU) - L3 packet	9000 bytes
Jumbo frame - Ethernet frame	9018 bytes

Life is too short to live without the Cisco Catalyst 2960-24PC L2 Switch, 24*10/100 PoE Ports, 2*T/SFP, LAN Base Image WS-C2960+24PC-L Gigabit Ethernet Enterprise Switch. Be happy. Be Content. Be Satisfied.
