Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
  • Load image into Gallery viewer, Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
  • Load image into Gallery viewer, Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
  • Load image into Gallery viewer, Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR
  • Load image into Gallery viewer, Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR

Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR

R 24,222.91
R 24,222.91
R 31,960.78
Sold out
Shipping calculated at checkout.

Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR

SPECIFICATIONS

ACL: MAC IPv4 IPv6 Standard Extended

ARP: Supported

Brand Name: keepLiNK

Buffer: 4.1M

Certification: CE,FCC,RoHS,pse

Communication Mode: Full-Duplex & Half-Duplex

DHCP Client: Supported

DHCP Interface Priority IP Binding: Supported

DHCP Server: Supported

DNS Client: Supported

DNS Server: Supported

Device Scanning: Supported

Dimension: 440 x 284 x 44 mm

Duplex Mode: Supported

EEE: Supported

Ethernet Ring Protection Switching: Supported

Ethernet channel/ 802 .3ad: Supported

Fixed port: 4 x 1000 Combo and 24 x 10/100/1000 Base-T

Flow Control: Supported

Forwarding delay: <10us

Function: LACP,POE,QoS,SNMP,VLAN Support

GVRP VLAN: Supported

High-concerned chemical: None

IGMP Snooping: Supported

IPV4 management: Supported

IPV6 management: Supported

Input voltage: AC 100-240V 50/60Hz

Installation Method: Rack mounted

Interface Speed: Supported

Jumbo Frame: Supported

LACP: Supported

LED Indicators: PWW SYS Link or ACT

LLDP: Supported

LLDP 802.1 TLV: Supported

Loopback Interface: Supported

MAC VLAN: Supported

MAC address table: 8K

MDI/MDIX: Supported

MLD Snooping: Supported

MSTP / RSTP / STP: Supported

MTBF: 100,000 hours

MVR: Supported

Management Port: console

Model Number: 28GCPM-B2C4-ACR

Number of Interfaces: 28

Operating humidity: 10%~90% RH

Operating temperature: -10℃~+50℃

Package: Yes

Packet forwarding rate: 41.616Mpps

PoE Management: Supported

PoE Protocol: IEEE802.3af/at/bt

PoE port: 1 to 24

PoE++: 1 to 2

Port Statistics: Supported

Protected Ports: Supported

Protocol VLAN: Supported

QoS: Remarking Port Trust Limit SP WRR COS DSCP IP Priority

SNTP Client: Supported

STP BPDU Filter: Supported

STP BPDU guard: Supported

STP Port Fast: Supported

Standby Power: 22W

Static Routes IPV4: 32

Static Routes IPv6: 32

Storage humidity: 5%~90% RH

Storage temperature: -40℃~+75℃

Surveillance VLAN: Supported

Switch Capacity: 56G

Switch Type: Gigabit Switch

Thermal methods: Fan cooling

Topology: Ring Star Bus Tree and Hybrid

Total Power consumption: 400W

Transmission Rate: 10/100/1000Mbps

VLAN: Yes,256

Voice VLAN: Supported

Weight: 3.4 kg

Description

The 28GCPM-B2C4-ACR is a Layer 3 Managed PoE++ Switch with 24x Gigabit RJ45 ports (Ports 1-2: 90W PoE++, Ports 3-24: 30W PoE+) and 4x Gigabit combo uplinks. Features 802.3at/bt compliance, QoS prioritization, store-and-forward switching, and 400W total PoE budget for high-power devices like PTZ cameras and WiFi 6 APs. Ideal for enterprise and industrial networks requiring reliable power and data delivery.



Key Features:

● 24x Gigabit RJ45 Ports – Ports 1-2 support 90W PoE++ (802.3bt), Ports 3-24 support 30W PoE+ (802.3at)
● 4x Gigabit Combo Uplinks (SFP/RJ45) – Flexible fiber or copper uplink options
● 400W Total PoE Budget – Powers high-demand devices like PTZ cameras, WiFi 6/7 APs, and VoIP phones
● Layer 3 Managed Switching – Supports VLAN, QoS, ACL, and advanced routing for optimized traffic
● Store-and-Forward Switching – Ensures reliable data transmission with wire-speed forwarding
● Auto MDI/MDIX – No need for crossover cables; auto-detects connection type
● Robust Security & Management – CLI, SNMP, Web GUI, and RMON for easy monitoring

Applications:

● IP Surveillance Systems – Powers PTZ cameras, NVRs, and PoE lighting
● Enterprise WiFi Networks – Supports WiFi 6/7 access points with high-power PoE++
● Smart Buildings & Offices – Connects VoIP phones, digital signage, and access control systems
● Industrial Networks – Rugged, reliable PoE for factory automation & IoT devices
● Education & Healthcare – Stable connectivity for classroom AV systems & medical devices



Ideal for IT professionals, system integrators, and enterprises needing scalable, high-power PoE switching with advanced management.

The Bullscom 24-Port Managed PoE++ Switch 4x Gigabit Uplinks, L3 QoS, 802.3at/bt, 370W Budget 24x 10/100/1000Base-T 28GCPM-B2C4-ACR is the product you didn't think you need, but once you have it, something you won't want to live without.
