Brocade G610 24 port switch, 16 port activation, including 16 Brocade 16Gb/s shortwave multi-mode modules, port side exhaust BR-G610-16-16G-0

R 262,515.95
R 262,515.95
R 336,020.95
Sold out
Shipping calculated at checkout.

Brocade G610 series 24 port switch, 16 port activation, including 16 Brocade 16Gb/s shortwave multi-mode modules, port side exhaust

Description

Brocade G610-16-16G-0 switch from the G610 series is a high-performance 24-port switch with 16 activated 16Gb/s shortwave multi-mode modules. It features port-side exhaust and is ideal for engineers and procurement personnel seeking reliable and scalable network infrastructure solutions.

BR-G610-16-16G-0 Product Highlights

  • Provides exceptional price/performance value, combining flexibility, simplicity, and enterprise-class functionality in a 48-port
  • Enables fast, easy, and cost-effective scaling from 24 to 48 ports
  • Leverages Brocade Fabric Vision technology’s powerful monitoring, management, and diagnostic tools to simplify administration, increase uptime, and reduce costs
  • Helps pinpoint problems faster and simplify SAN configuration and management with Brocade Network Advisor
  • Simplifies deployment with the Brocade EZSwitchSetup wizard and supports high-performance fabrics by using Brocade ClearLink D_Ports to identify optic and cable issues
  • Maximizes availability with redundant, hot-pluggable components and non-disruptive software upgrades

Product Features Comparison

Features BR-G610-16-16G-0 BR-G610-24-16G-0 BR-G620-32-16G-0 Cisco MDS 9148S 16G Huawei S5700-52X-LI Juniper EX3400-48T
Ports 24 24 32 48 48 48
Activated Ports 16 16 32 16 24 24
Transmission Speed 16Gb/s 16Gb/s 16Gb/s 16Gb/s 10Gb/s 10Gb/s
Support Type Multi-mode Multi-mode Single-mode Single-mode Multi-mode Multi-mode
Cooling Port side exhaust Port side exhaust Port side exhaust Port side intake Port side exhaust intake Port side exhaust
Form Factor 1RU 1RU 1RU 1RU 1RU 1RU

BR-G610-16-16G-0 Product Application Scenarios

  • Data center interconnects
  • High-performance computing
  • Enterprise network cores

Optional Add-ons

Model Description
BR-16G-SW-16 16Gb/s Shortwave Multi-mode SFP+ Module
BR-SFP-16G-LW-2 16Gb/s Longwave Single-mode SFP+ Module
BR-4G-CU-3M 4Gb/s Direct Attach Cable, 3 meters

Technical Specifications

BR-G610-16-16G-0 Specification
Fibre Channel ports Switch mode (default): 8-, 16-, and 24-port configurations (8-port increment through Ports on Demand [PoD] license); E_Ports, F_Ports, M_Ports, and D_Ports
Brocade Access Gateway default port mapping: 16 F_Ports, 8 N_Ports
Scalability Full-fabric architecture with a maximum of 239 switches
Certified maximum 6,000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required
Performance Fibre Channel: 4.25Gb/s line speed, full duplex; 8.5Gb/s line speed, full duplex; 14.025Gb/s line speed, full duplex; 28.05Gb/s line speed, full duplex; auto-sensing of 4, 8, 16, and 32G port speeds.
ISL trunking Frame-based trunking with up to eight 32G SFP+ ports per ISL trunk; up to 256Gb/s per ISL trunk.
Exchange-based load balancing across ISLs with DPS included in Brocade Fabric OS fabrics
Aggregate bandwidth 768 Gbps end-to-end full duplex
Maximum fabric latency Latency for locally switched ports is 700 ns; Forward Error Correction (FEC) adds 400 ns between E_Ports (enabled by default).
Maximum frame size 2,112-byte payload
Frame buffers 2000 dynamically allocated
Classes of service Class 2, Class 3, Class F (inter-switch frames)
Port types F_Port, E_Port, M_Port, D_Port (ClearLink Diagnostic Port) on 24 SFP+ ports
Brocade Access Gateway mode: F_Port and NPIV-enabled N_Port
Data traffic types Fabric switches supporting unicast
Size Width: 428.80 mm (16.88 in.)
Height: 42.90 mm (1.69 in.)
Depth: 306.60 mm (12.07 in.)
System weight 4.20 kg (9.26 lb) with one integrated power supply and fans, without transceivers
4.80 kg (10.58 lb) with one integrated power supply and fans, fully populated with transceivers
Operating environment Temperature: 0°C to 40°C/32°F to 104°F
Humidity: 10% to 85% (non-condensing)
Non-operating environment Temperature: –25°C to 70°C/–13°F to 158°F
Humidity: 10% to 90% (non-condensing)
Operating altitude Up to 3,000 m (9,843 ft)
Storage altitude Up to 12 km (39,370 ft)
Power supply Base switch includes a single, hot-swappable power supply with integrated system cooling fans. Optional dual redundant hot-swappable power supply.
AC input 90V to 264V, maximum input current: 2.2A
Input line frequency 47 Hz to 63 Hz
Power consumption 76.52W with all 24 ports populated with 32G SWL optics
55.83W for idle configuration (all optics loaded but not initialized)
