Brocade BR-G720-48-32G-R G720 48 Active Ports FC SAN Switch with 48x 32Gb SWL SFP+ Industrial Network 48-Port Fibre Channel BR-G720-48-32G-R

Regular price: R 2,237,711.41
Sale price: R 2,237,711.41
Regular price: ~~R 2,632,601.66~~
Unit price: per

Shipping calculated at checkout.

Color

Quantity must be 1 or more

SPECIFICATIONS

Brand Name: Brocade

Certification: Other

Chassis height(U): 1U

Condition: New and Original

DIY Supplies: Electrical

Dimensions (W x D x H): 442 mm x 420 mm x 43.6 mm

Electronic: Yes

Fixed ports: 24 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28

High-concerned chemical: None

Origin: Mainland China

Product Code: BR-G720-48-32G-R

Brand Name: Brocade

Communication mode: Full-Duplex

Function: POE

Model number: BR-G720-48-32g-R

Ports: 24

Private Mold: Yes

Products status: Stock

Switch Capacity: 10/100/1000Mbps

Transmission rate: 10/100/1000Mbps

Product Description

Brocade Industrial Network 48-Port Fibre Channel Switch BR-G720-48-32G-R

BR-G720-48-32G-R Specification
Fibre Channel ports	Switch mode (default): Minimum of 24 ports and maximum of 64 ports configuration. Port numbers above minimum are enabled through 12-port SFP+ increments via Ports on Demand (PoD) licenses and through one 4-port QSFP PoD, providing 16-port increments through a Q-Flex license; E_Ports, F_Ports, M_Port, D_Ports, EX_Ports. Brocade Access Gateway default port mapping: 40 SFP+ F_Ports, 8 SFP+ N_Ports
Scalability	Full-fabric architecture with a maximum of 239 switches
Certified maximum	6,000 active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics; larger fabrics certified as required
Performance	Fibre Channel: 4.25Gb/s line speed, full duplex; 8.5Gb/s line speed, full duplex; 14.025Gb/s line speed, full duplex; 28.05Gb/s line speed, full duplex; auto-sensing of 4, 8, 16, and 32G port speeds. 10G optionally programmable to fixed port speed. Auto-sensing of 4×32/4×16/4×8/4×4 Gb/s speeds on the QSFP ports with Brocade FOS v8.2.0.
ISL trunking	Frame-based trunking with up to eight 64G SFP+ ports per ISL trunk; up to 512Gb/s per ISL trunk; up to two (4 x 32G) QSFP ports per ISL trunk. Exchange-based load balancing across ISLs with DPS included in Brocade Fabric OS.
Aggregate bandwidth	2Tb/s
Maximum fabric latency	Latency for locally switched ports is <780 ns (including FEC); compression is 1 μs per node.
Maximum frame size	2,112-byte payload
Frame buffers	15,360 dynamically allocated
Classes of service	Class 2, Class 3, Class F (inter-switch frames)
Port types	F_Port, E_Port, M_Port, D_Port (ClearLink Diagnostic Port) on 24 SFP+ ports Brocade Access Gateway mode: F_Port and NPIV-enabled N_Port
Data traffic types	Fabric switches supporting unicast
Size	Width: 440.00 mm (17.32 in.) Height: 43.90 mm (1.73 in.) Depth: 355.60 mm (14.00 in.)
System weight	7.07 kg (15.59 lb) with two power supplies, fans, without transceivers 8.41 kg (18.54 lb) with two power supplies, fans, fully populated with transceivers
Operating environment	Temperature: 0°C to 40°C/32°F to 104°F Humidity: 10% to 85% (non-condensing)
Non-operating environment	Temperature: –25°C to 70°C/–13°F to 158°F Humidity: 10% to 90% (non-condensing)

The Brocade BR-G720-48-32G-R G720 48 Active Ports FC SAN Switch with 48x 32Gb SWL SFP+ Industrial Network 48-Port Fibre Channel BR-G720-48-32G-R is evocative, to say the least, but that's why you're drawn to it in the first place.
