Cisco Meraki MR28 Wi-Fi 6 Indoor Access Points dual-band, 802.11ax, 2x2:2, cloud-managed entry-level access point MR28-HW

Description

The MR28 is a 2x2:2 MU-MIMO 802.11ax access point that supports up to 1.5* Gbps dual-radio aggregate frame rate.

Entry Level Cloud Managed Wi-Fi 6 Access Point

The Cisco Meraki MR28 is a dual-band, 802.11ax, 2x2:2, cloud-managed entry-level access point. Designed for basic, medium-density deployments, the MR28 provides enterprise-grade security and simple management.

The MR28 provides a maximum of 1.5 Gbps* aggregate frame rate with concurrent 2.4 GHz and 5 GHz radios.

With the combination of cloud management, high-performance hardware, multiple radios, advanced software features, enterprise-grade security, the MR28 makes an excellent platform to provide reliable Wi-Fi for small business and home office networks that want reliable and secure wireless connectivity.

MR28 and Meraki Cloud Management

Management of the MR28 is performed through the Meraki cloud, with an intuitive browser-based interface that enables rapid deployment without time-consuming training or costly certifications. Because the MR28 is self-configuring and managed over the web, it can be deployed at a remote location in a matter of minutes, even without on-site IT staff.



24x7 monitoring via the Meraki cloud delivers real-time alerts if a network encounters problems. Remote diagnostic tools enable immediate troubleshooting over the web so that distributed networks can be managed with a minimum of hassle.



The MR28’s firmware is automatically kept up to date via the cloud. New features, security fixes, and enhancements are delivered seamlessly over the web. This means no manual software updates to download or missing security patches to worry about.

Product Highlights

  • 2x2:2 MU-MIMO 802.11ax

  • 1.5* Gbps dual-radio aggregate frame rate

  • Enhanced transmit power and receive sensitivity

  • Integrated enterprise security and guest access

  • Application-aware traffic shaping

  • Optimized for voice and video

  • Self-configuring, plug-and-play deployment

Features

Dual–radio aggregate frame rate of up to 1.5 Gbps*

5 GHz 2x2:2 and 2.4 GHz 2x2:2 radios offer a combined dual–radio aggregate frame rate of 1.5 Gbps*, with up to 1,201 Mbps in the 5 GHz band and 287 Mbps in the 2.4 GHz band.

* The radio chipset supports an aggregate PHY data rate of 1.7Gbps (1,201 Mbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band).

Specifications

Category

Specifications

Radios

  • 2.4 GHz 802.11b/g/n/ax client access radio

  • 2.4 GHz Bluetooth® Low Energy (BLE 5) radio with Beacon and BLE scanning support

  • 5 GHz 802.11a/n/ac/ax client access radio

  • Supported frequency bands (country-specific restrictions apply)

  • Supported frequency bands (country-specific restrictions apply):

    • 2.412 - 2.484 GHz

    • 5.150 - 5.250 GHz (UNII-1)

    • 5.250 - 5.350 GHZ (UNII-2A)

    • 5.490 - 5.730 GHz (UNII-2C)

    • 5.735 - 5.825 GHz (UNII-3)

Antenna

  • Internal Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)

802.11ax, 802.11ac Wave 2 and 802.11n Capabilities

  • DL-OFDMA**, UL-OFDMA**, TWT support**, BSS Coloring**

  • 2 x 2 multiple input, multiple output (MIMO) with two spatial streams

  • SU-MIMO, UL MU-MIMO** and DL MU-MIMO support

  • Maximal ratio combining (MRC) & beamforming

  • 20 and 40 MHz* channels (802.11n); 20, 40*, and 80 MHz channels (802.11ac Wave 2); 20, 40* and 80 MHz channels (802.11ax)

    Note: *40MHz channels are supported only in the 5GHz band.

  • Up to 1024-QAM on both 2.4 GHz & 5 GHz bands

  • Packet aggregation

Power

Note: Only MA-PWR-30W-XX (XX - AU, EU, CN, UK, US) AC adapters are compatible with MR28. Previous generations of AC adapters are not compatible with MR28.

  • Power over Ethernet: 37 - 57 V (802.3af compatible)

  • Power consumption: 15W max (802.3af).  Note: actual power consumption may vary depending on the AP usage.

  • Power over Ethernet injector sold separately

Note: Actual power consumption may vary depending on the AP usage.

Interfaces

  • 1x 10/100/1000 BASE-T Ethernet (RJ45)

Physical Security

  • Two security screw options (included) (10 mm long and 2.5 mm diameter and 4.7 mm head)

  • Concealed mount plate with anti-tamper cable bay

Environment

  • Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)

  • Humidity: 5 to 95% non-condensing

  • Operating altitude: Up to 40,000 feet (12,192 meters)

Reliability

  • Mean Time Between Failure (MTBF): 257,215hrs at +25°C operating temperature

Physical Dimensions

  • 7.95” x 4.88” x 1.02” (202 mm x 124 mm x 25.8 mm), not including deskmount feet or mount plate

  • Weight: 9.6 oz (272 g)
