Zyxel LTE Id Router with Battery Compartment, Wi-Fi Router, wireless broadband connectivity and seamless switching among 4G LTE, DC-HSPA+, 3G, EDGE

Zyxel LTE Id Router with Battery Compartment, Wi-Fi Router, LTE3302

Description

The Zyxel LTE3302 Series provides wireless broadband connectivity and seamless switching among 4G LTE, DC-HSPA+, 3G, EDGE and GPRS that allows the freedom to surf the Internet and access any information at home, in the office or anywhere under LTE coverage without wire connection.

FEATURES:

- Embedded bridge/router mode adapts to most devices/gateways:

For better network integration, Zyxel embeds both bridge and router modes into the Zyxel LTE3302 Series. Users can take advantage of the built-in routing functions in all typical applications, while the bridge mode is designed to work with users’ existing or preferred devices such as high-end WiFi access points, small business gateways or enterprise gateways.

- Continuity Internet sharing:

With Micro USB power port, you can use it as a portable router when you’re traveling, fishing or watching football games. As higher-capacity power banks or car chargers are widely available, it’s easy to use the Zyxel LTE3302 Series for an extended time for continuous Internet sharing.

- Non-stop connectivity with LTE 2nd WAN for fail-over:

Multi-WAN fail-over relieves the risk of network outage depending on single WAN technology. Even better, wireless LTE connectivity allows you to maintain a second WAN option without a cable plan. As long as the gateway supports “multi-WAN fail-over”, you can just connect the Zyxel LTE3302 Series to an existing gateway and set LTE as the fail-over WAN.

- Circuit-switched and VoLTE support for seamless voice migration*:

Technologies behind voice services vary by operators; some utilize the “packet-switched” method and some choose “circuit-switched”. Thanks to the LTE3312 supports to both technologies, you don’t have to worry about voice functions supported by your operator. You can easily migrate the voice functions to LTE3312 Series over LTE network.

SPECIFICATIONS:

IP Networking:
- Support IPv4 and IPv6 dual stack
- DHCP
- Dynamic and fixed IP address assignment on LAN side
- VPN pass through
- Firewall
- NAT/NAPT
- Port forwarding/DMZ
- DNS/DDNS
- Supports NAT Router mode
- Supports Bridge mode (IP pass-through)
WiFi Security:
- WEP: 64/128-bit
- WPA/WPA2:
- Support WPA2 primarily, and automatic fallback to WPA for clients that do not support WPA2
- WPA/WPA2-PSK
- MAC Address Filter with 32 address supported

Management:
- APN management
- SIM PIN management
- SMS management
- Secure remote management via WebGUI/SSH
- Over-The-Air (OTA) firmware upgrade: TR-069/WebGUI
Voice Service (LTE3312):
- CS-Voice: Standard compliant: 3GPP TS 23.272 Release 9
Support CSFB from LTE to 3G
- Voice over LTE: GPP/GSMA IR.92 compliant
Supports Audio CODEC: G.711 (U-law), AMR, AMR-WB, EVRC
DTMF over RTP
Voice Activity Detection (VAD)
Comfort Noise Generation (CNG)

LTE Air Interface:
- Standard compliant: 3GPP Release 9 category
- Supported frequency band:
- Band LTE B1/2/3/5/7/8/20/28/38/40
- LTE TDD 2300/2600 MHz
- LTE FDD 2600/2100/1900/1800/900/850/800/700 MHz
- LTE/3G/2G internal antenna: x2
- LTE/3G/2G external SMA-F connectors: x2
- Peak data rate:- 150 Mbps DL within 20 MHz bandwidth
- 50 Mbps UL within 20 MHz bandwidth
UMTS/GSM Air Interface:
- Standard compliant: DC-HSDPA/ HSPA+ compliant
- Supported frequency:- HSPA+/UMTS, B1/5/8 (2100/900/850 MHz)
- EDGE/GPRS/GSM, B2/3/5/8 (1900/1800/900/850 MHz)
- DC-HSPA+ downlink data rate up to 42 Mbps
- HSUPA uplink data rate up to 5.76 Mbps
- UMTS data rate up to 384 kbps
- EDGE data rate up to 236.8 kbps
- GPRS data rate up to 85.6 kbps
WiFi Air Interface:
- IEEE 802.11 b/g/n, 2.4 GHz, data rate up to 300 Mbps
- WiFi enabled device #: up to 32
- Multiple SSIDs support
- WiFi antenna: 2 internal antennas up to 3 dBi

Hardware Interface:
- Two 10/100 Mbps Ethernet RJ-45 LAN ports
- One RJ-11 FXS port (LTE3312)
- LEDs:- Power & signal and quality
- Internet status/SMS
- WiFi status
- LAN status
- Battery status
- One 2FF format mini SIM card slot
- One power on/off button
- One WLAN/WPS button
- One reset to default button
- Two SMA connectors for 4G LTE/3G/2G connection
- Micro USB power port (5V/2A)
Battery (Optional):
- Removable lithium-ion polymer battery
- 3.8V, 2800 mAh
- Up to 4 hours operating time (depends on network environment)

Physical Specifications:
- Dimensions (WxDxH): 130 x 130 x 45 mm
Environmental Specifications:
- Operating Environment:- Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 10% to 90% (Non-condensing)
- Storage Environment:- Temperature: -30°C to 70°C (-22°F to 158°F)
- Humidity: 0% to 95% (Non-condensing)
Power Specification:
- External power supply: 110 - 240 VAC/5V 2A DC adaptor
- Power consumption at peak: 10W (peak)
