TP-Link AX6000 WiFi6 Turbo Edition Dual-Band Gigabit Wireless Router, High-Speed 5G Easy Exhibition 4x4 MU-MIMO 2.4G + 5G TLXDR6060

Hardware specifications

Hardware specifications

Wi-Fi

Size and weight

IEEE 802.11a/b/g/n/ac/ax wireless protocol

Bare machine size (length × width × height): 287×287×153mm

Maximum wireless rate 5952Mbps (2.4GHz 1148Mbps, 5GHz 4804Mbps)

Package size (length × width × height): 342.5*342.5*217.5mm

Beamforming (Beamforming)

Bare machine weight: 1.294kg (single unit, excluding accessories and packaging)

4×4 MU-MIMO

Weight of the whole machine: 2.776kg (single unit, including accessories and packaging)

WMM: Priority-based data processing and forwarding

Antenna type

Wi-Fi multi-frequency integration

External omni-way antenna: 4 2.4G antennas, 4 5G antennas

Easy exhibition function

Software functions

Ethernet port

Wireless bridging

3 10/100/1000Mbps rate adaptive LAN ports, 1 10/100/1000Mbps rate adaptive WAN/LAN adaptive port; 1 2.5Gbps rate adaptive Ethernet
interface, supporting WAN/LAN adaptive (blind plugging of the network port); 1 Gigabit optical fiber port

Signal adjustment

USB port

Terminal management

2 USB 3.0 ports

IP and MAC address binding

Other

AP isolation

Power supply

Virtual server

DC power supply, factory delivery 12V/4A power adapter

Dynamic Domain Name Service (DDNS)

Packing list

DMZ host

1 router

Automatic cleaning

Power adapter 12V/4A 1

Wireless timing switch

Network cable (1 meter) 1

Local Online/Local Firmware/Remote Upgrade

Quick installation guide 1 copy

Manage

1 parameter record sticker

Computer/Mobile/Pad Web Management

Mobile APP management

Safe

WPA-PSK, WPA2-PSK, WPA3 wireless encryption

Host network, visitor network

Administrator status is limited
