Original ZTE Portable WiFi 5G Router MU5001 LTE CAT22 WIFI 6 1800Mbps NSA+SA Mobile Hotspot 5G Router With Sim Card Slot
Description
Original ZTE Portable WiFi 5G Router MU5001 LTE CAT22 WIFI 6 1800Mbps NSA+SA Mobile Hotspot 5G Router With Sim Card Slot - 5G Router MU5002 LTE CAT22 WIFI 6 1800Mbps NSA+SA Mobile Hotspot 5G Router With Sim Card Slot
Specifications
With Modem Function: No
Wired Transfer Rate: 10/100/1000Mbps
Wi-Fi Transmission Standard: 802.11g
Wi-Fi Supported Frequency: 2.4G & 5G
Type: Wireless
Supports WPS: Yes
Supports WDS: Yes
Standards And Protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n
Package: Yes
Max. LAN Data Rate: 1750Mbps
Function: Firewall
Certification: CE
Brand Name: ZTE
Application: Home
5G Wi-Fi Transmission Rate: 2167Mbps
2.4G Wi-Fi Transmission Rate: 600Mbps
Key Features:
Support 5G, speed up to D/L 3.8Gbps
Qualcomm SDX55 platform(QCA6391)
Wi-Fi 802.11 b/g/n/ac/ax, 2.4G&5G Dual Band, 2*2MIMO
32 Wi-Fi users , Wi-Fi 6 up to 1775Mbps(AX 1800)
2.4 inch color touch screen (QVGA 320 x 240)
1 Gigabit Ethernet Port (RJ45)
1 Type-C (USB 3.1)
1 SIM card slot (Nano-SIM)
2 Antenna ports (TS-9)
4500mAH battery (Quick Charge 3.0)
Customer management via WebUI or ZTELink APP (iOS or Android)
Dimensions: 133x73x18.5mm
Weight: 220g
Support operating system: iOS, Android, Windows, Linux Mobile phone/tablet/computer/set-top box etc…
ZTE MU5001, 5G/CAT20 Unlocked, Portable WiFi 6 Hotspot, Connect 32 Devices, 4500mAh Battery with Quick Charge
ZTE 5G Mobile WiFi Router MU5001
Chipset | SDX55 | ||
SRS | Yes | N41, N77, N78 | |
Waveform |
CP-OFDM for UL&DL DFT-s-OFDM for UL |
Yes | |
Sub Carrier | Sub6G: 30KHz, 15KHz | Yes | |
Main antenna | Internal antenna and External antenna interface | Yes |
There are two external Antenna ports: one is for n77 one is for n41/77/78,LTE B1/3/7(RX) |
GSM band | Doesn't support 2G. | No | |
UMTS band | B1/2/5/8 | Yes | |
LTE band | LTE:B1/3/5/7/8/20/28/38/40/42/43 | Yes | |
5G Sub6 Band |
NR SA:N1/3/5/7/8/20/28/38/41/77/78 NR NSA:N1/3/7/8/28/38/40/41/78 |
Yes | |
5G mmWave Band | Doesn't support mmWave. | No | |
MIMO for wireless |
5G Sub6: N78 supports 4*4MIMO LTE: 1/3/7 supports 4MIMO |
Yes | |
transmitter power for wireless |
26dBm for N78 23dBm for other bands |
Yes | |
WiFi band | 2.4G & 5G | Yes | |
MIMO for WiFi | 2*2 MIMO for both 2.4G&5G | Yes | |
MU-MIMO |
Specifications MU5001
- Wired Transfer Rate: 10/100/1000Mbps
- Wi-Fi Transmission Standard: 802.11ac
- Wi-Fi Supported Frequency: 2.4G & 5G
- WAN Ports: 1 x10/100/1000Mbps
- Function: Firewall
- Application: Mini Wifi
- Package: Yes
- Standards And Protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac
- With Modem Function: No
- Type: Wireless
- Brand Name: ZTE
- Certification: CE
- Antenna type: Built-in
- Other interfaces: 1*USB3.1
- VPN support: Support
- Product Type: Pocket WiFi
MU5002
Snapdragon X55 with maximum download speed of up to 3.8 Gpbs
Snapdragon X5 platform
The Snapdragon*55 baseband is manufactured using the most advanced 7nm process,and the peak rate in EN-DC mode can reach 3.8 Gbps.A 5G SIM card,ZTE protable WiFi6,converts 5G into Wi-Fi Signal and Gigabit network signal,allowing mobile phones,tablets,laptops,desktops,and enjoy 5G high speed
A two-color design with a touchscreen display
4500mAh quick charge,a battery that can last up to 9 hours
The 4500mAh battery can be used for more than 9 hours in a typical user scenario.allowing 5G to be online at any time.Support Qualcomm QC3.0 fast charge protocol, fully charged in 150 minutes.Support reverse charging function,with dedicated line,ZTE protable WiFi can become a power bank in 6 seconds,the maximum charging power reaches 10W.
