High Frequency Inverter Converter dc to ac 110V 120V 800W Inverter 2U Single-phase Power Supply for Data Center Telecoms
SPECIFICATIONS
High-concerned Chemical: None
DIY Supplies: ELECTRICAL
Certification: CE
Network: LAN
Customized support: Software re-engineering, Frequency, Output Voltage, Appearance, Back Panel
Brand Name: BVITTECH
Model Number: BVT110/120-1KVAR
Type: DC/AC Inverters
Output Type: Triple
Output Current: 7.27A
Output Frequency: 60Hz, 50Hz
Size: 482*347*88mm
Weight: 11Kgs
Efficiency: ≥85%, 85%(Max. 92%)
Rated power: 800W
Product name: Telecom Inverter
Application: Data Center
Warranty: 12 Months
Protection: Short Circuit Overload Overvolt Overtemp
Output waveform: Prue Sine Wave
Input Voltage: 110Vdc
Output Voltage: 120Vac
OEM&ODM: Acceptable
BVITTECH Pure Sine Wave Rack Mount Inverter
BVT110/120-1KVAR
Product Features:
* True sine wave output (T.H.D < 3%)
* Transfer time <5ms * LCD Display, LED Indicator * Five sets of passive dry contacts * RS232 and RS485 & Optional SNMP communication Port * By-pass AC 220V input filtering; * Real-time monitoring of the system operating status; * Audible and visual alarm; * Record the historical alarm message and can be queried; * Start auto restart while Ac or Dc is recovering; * Maintenance bypass /DC available; * Unattended operation: the system switches automatically to provide AC Power to the load between the DC input and AC input
Products Description
Technical Specifications
Model |
BVT110/120-1KVAR |
|||
DC Input |
||||
Rated Input Voltage(Vdc) |
110V |
|||
Rated Input Current (A) |
9.09A |
|||
DC Input Range (Vac) |
85-135V |
|||
Reflected Noise Current. |
≤10% |
|||
AC Bypass Input |
||||
Bypass Voltage Range (Vac) |
170V-280V(±10V) |
|||
Rated Input Current(A) |
9.09A |
|||
AC Output |
||||
Capacity(VA) |
1KVA |
|||
Rated output Capacity(W) |
800W |
|||
Output Voltage and Frequency |
120Vac,50HZ |
|||
Output Current(A) |
7.27A |
|||
Voltage Accuracy(V) |
120±1.5% |
|||
Frequency Accuracy(Hz) |
50±0.1% or60±0.1% |
|||
Waveform |
Pure Sine wave |
|||
THD |
≤3%(Line) |
|||
Dynamic Response Time |
5%((Load0←→100%) |
|||
Power Factor(PF) |
0.8 |
|||
Overload Capability |
100%-120% 60s, 121%-150% 10s |
|||
Inverter efficiency(80% line load) |
≥85% |
|||
Inverter ←→ Bypass(ms) |
≤5ms |
|||
General |
||||
Dielectric Strength(Input & Output) |
1500Vac-10mA,1minutes |
|||
Noise(1m) |
≤55dB |
|||
Ambient Temp. |
-20℃~+50℃ |
|||
Humidity |
0~90%,No condensation |
|||
Altitude(m) |
≤2000 |
|||
LCD Display |
Input/output Voltage, Frequency, Output Current, Temp, Capacity Rate, etc. |
|||
Inverter Status |
Off Grid Status, Inverter Status, Batter Under&Over Vol, Output Over load |
|||
Dimensions(D×W×H)(mm) |
Standard 19”Rack mount, 347X482X88 |
|||
Protection |
Input under Voltage, Input over Voltage,Output Over load, Short circuit |
